Cable FELSTED X0220 RVC HUB.

Description & Features

The Cable Felsted X0220 RVC Hub by Orscheln Products LLC ensures robust performance in harsh environments. Featuring a hi-performance 1 x 7 coated core this cable is engineered for flexibility and higher push loads.

A heavy-duty thick-walled polymer jacket in dark maroon enhances cable strength while corrosion-resistant materials in end fittings ensure prolonged durability. End fittings comprise 300 series stainless steel rods and sleeves with hubs constructed from either aluminum or stainless.

Utilizing exclusive polymer liners the cable maintains an optimal temperature range of -65F to 225F. Factory lubrication ensures maximum core performance without further service needs. The inclusion of a polymer rod and sleeve bearing prevents metal-to-metal contact promoting superior sealing and extended cable life.

Custom compounded seals effectively prevent moisture and contaminants from entering the cable. Stranded conduit with oil-tempered spring wires offers minimal deflection and precise control during operation.

MPN: X0220

Supplier Part Number: X0220

Specifications

Brand
ORSCHELN®
Sg Conduit Jacket
Heavy-Duty, Thick-walled Polymer Jackets are Extruded Onto the Stranded Liner for Maximum Cable Strength, Standard Material is Hope Molded to A Dark Maroon Color
Sg Core Construction
Hi-performance (Hp) 1 x 7 Coated Core is Available in 3, 4 and 6 Series Cables, HP Core Utilizes A Proprietary Coating over 1 x 7 Wire Rope Which Offers Improved Flexibility and Higher Push Loads than Armor Core Construction, Solid Stainless Steel Cores a
Sg End Fittings
Corrosion-resistant Materials are Used Throughout to Provide Maximum Life, Standard 3, 4 and 6 Series Rods and Sleeves are 300 Series Stainless Steel, While Hubs are Either Aluminum or Stainless
Sg Liners
All Cables Utilize Polymer Liners Which Have A Temperature Rating of -65 to 225 deg F, Factory Lubrication Provides Optimum Core Performance Without Requiring Further Service
Sg Rod Sleeve Bearing
An Exclusive Polymer Rod and Sleeve Bearing is Used to Improve Efficiency, Sealing and Cable Life by Preventing Metal to Metal Contact Between the Rod and Sleeve, They also Accurately Align the Rod with the Seal to Insure Superior Sealing and A Long Cable
Sg Seals Boots
Durable Custom Compounded Seals are Used to Prevent Moisture and Contaminants from Entering the Cable
Sg Stranded Conduit
Multiple, Oil Tempered Spring Wires are Placed in A Long Lay Pattern to Protect the Liner and Inner Core, Maintain Flexibility and Withstand Extreme Compressive and Tensile Loads, This Long Lay Construction Results in Minimal Deflections During Cable Oper

Similar Products

Model Number Thread Size Length For Use With Price Action
Cable FELSTED 3 SERIES CLAMP.

39001 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSED CLEVIS 5/16-24 TH.

000-69003-0001 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable FELSTED ROD PIVOT.

000-49042-0000 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED STOP COLLAR.

30103 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED CABLE PART.

39006 Cable Hardware & Knob

#10-32 x 1/4-28

3 Series Solid Core Cables

Cable FELSTED PIVOT (4 SERIES).

000-49008-0001 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED FRICTION CONTROL.

055887-000000 Cable Hardware & Knob

Cable FELSTED BALL JOINT.

000-69007-0000 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable FELSTED SWITCH KIT.

000-50036-0001 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED BALL JOINT.

000-49006-0000 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED CLEVIS.

000-49003-0002 Cable Hardware & Knob

10-32

3 Series Solid Core Cables

Cable FELSTED X0276-1 SLEEVE 5 INCH TRAVEL.

40004-5 Cable Hardware & Knob

Cable FELSTED CABLE FIELD CLAMP 000-39030-0001.

39030-1 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED 3 SERIES SHIM.

39002 Cable Hardware & Knob

3 and 4 Series Solid Core Cables

Cable ORSCHELN FELSTED SERIES 3 CLEVIS.

000-39003-0001 Cable Hardware & Knob

10-32

3 Series Solid Core Cables

Cable FELSTED BALL JOINT 4 SERIES.

000-49007-0000 Cable Hardware & Knob

1/4-28 x 5/16-24

4 Series Solid Core Cables

Cable FELSTED PIVOT For SOLID CORE.

39011-2 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED LOCKING PIVOT.

39011-1 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED SLEEVE X0102.

40202 Cable Hardware & Knob

Cable FELSTED BLACK 1/4-20 PLAIN T HANDL.

49005-1011 Cable Hardware & Knob

1/4-20

Cable FELSTED TERMINAL EYE.

000-49004-0001 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED RED PLAIN 1/4-20 X0081.

49005-2011 Cable Hardware & Knob

1/4-20

Cable FELSTED 4 SERIES ROD CLEVIS 1/4-28 THREA.

000-69003-0003 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED ROD CLEVIS 6 SERIES.

000-49003-0003 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable FELSTED VALVE KIT.

000-59112-0000 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED CLEVIS.

000-89003-0002 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable FELSTED TERMINAL EYE.

000-69004-0004 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable ORSCHELN FELSTED CLEVIS 1/4-28 UNF-2B FE.

000-49003-0001 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED PTO KNOB X0150.

30162 Cable Hardware & Knob

Cable FELST VLV OPER HUB X0147.

40203-10 Cable Hardware & Knob

Cable ORSCHELN FELSTED 4 SERIES CLAMP.

49001 Cable Hardware & Knob

4 Series Solid Core Cables

000-49004-0003

000-49004-0003

1/4-28

4 Series Solid Core Cables

FELSTED TERMINAL EYE

000-69004-0001

5/16-24

6 Series Solid Core Cables

Product Questions & Answers (1)

Question by: Earl F on Sep 20, 2025, 2:41 PM
What temperature range can this cable handle, cause I got some hot equipment?
Answer by: Customer Support on Sep 22, 2025, 1:26 PM
These Felsted cables use polymer liners rated from -65°F up to 225°F.
