Clearforce Non-Reinforced Non-Toxic FDA Unpressurized Potable Water-Drain-Vent PVC Hose, 1.00 Inch OD, 0.75 Inch ID, Up To 35.00 PSI

Ask A Question

Description & Features

The Clearforce Non-Reinforced Non-Toxic FDA Unpressurized Potable Water-Drain-Vent PVC Hose is designed for air and general purpose applications. With an outer diameter of 1.00 inch and an inner diameter of 0.75 inch, this hose operates effectively at up to 35 PSI. Its natural color and lightweight, flexible construction ensure suitability for food and beverage transfer lines, drain lines, pneumatic applications, and potable water transfer.

Made from premium polyvinyl chloride (PVC), it features excellent abrasion resistance and conductivity.

Eaton's clear PVC tubing products are manufactured to comply with FDA Regulation 21 CFR 177.1520 and are NSF-51 listed. The minimum bend radius is 4 inches, and it withstands temperatures ranging from +15deg;F to +150deg;F.

Fitting options include hose barb, hose clamps, and crimp ferrules.

Supplier Part Number: PT20016NA-100

Specifications

Abrasion Resistance
28
Application
Air and general purpose.
Color
Natural
Conductivity
30
Construction
Extruded
Cover Material
PVC
Dash Size
-16
Brand
Danfoss (Aeroquip Inc-Industrial Hose)
Brand
Aeroquip
Pack Size
1.00
UOM
FT
I.D.
0.75 in
Lay Line Style
Ink Jet
Maximum Working Pressure
35
Minimum Bend Radius
4
Minimum Bend Radius
4
Minimum Working Temperature
-5
O.D.
1 in
Package Qty.
100
Supplier Part Number
PT20016NA-100
Tube Material
Polyvinyl Chloride (PVC)
Alternate Part Numbers
Alternate Part Number C1KW12, Alternate Part Number H161216-100, Alternate Part Number MI-01291139, Alternate Part Number MINO-00015X15203, Alternate Part Number MINO-00925X90012
Product Weight
0.03 lbs

Related Documents

Similar Products

Model Number I.D. O.D. Maximum Working Pressure Burst Pressure Package Qty. Price Action
Clearforce Non-Reinforced Non-Toxic FDA Unpressurized Potable Water-Drain-Vent PVC Hose, 1.00 Inch OD, 0.75 Inch ID, Up To 35.00 PSI

PT20016NA-100 Clearforce Non-Reinforced PVC Hose

0.75 in

1 in

35

100

Product Questions & Answers (1)

Question by: Rod C on Dec 22, 2025, 1:14 PM
hose says "unpressurized" right in the name, does that mean I can't run it at any pressure at all, or is there some wiggle room there?
Answer by: Customer Support on Dec 24, 2025, 6:34 AM
Rated up to 35 PSI, so it does handle light pressure applications just fine. The "unpressurized" label in the name refers more to its intended primary use cases, things like drain lines, vent lines, and gravity-fed water transfer, where pressure isn't a factor. For air lines or low-pressure pneumatic setups under that 35 PSI ceiling, you're in good shape. Just don't push it past that working pressure limit.
