main product photo

Clearforce Reinforced Standard Duty PVC Hose, 0.75 Inch OD, 0.50 Inch ID, Up To 200.00 PSI

Ask A Question

Description & Features

Engineered for versatile use the Danfoss Clearforce Reinforced Standard Duty PVC Hose excels in a variety of industrial applications such as food and beverage transfer lines air lines drain lines sight gauges potable water transfer and pneumatic needs requiring higher pressure than standard PVC hoses.

Manufactured with premium materials this hose features a clear PVC construction reinforced by fiber for enhanced durability. The hose is non-marking lightweight and flexible all of which ensure long-lasting performance. With an outer diameter of 0.75 inches and an inner diameter of 0.50 inches it supports up to 200 PSI of pressure.

In compliance with FDA Regulation 21 CFR 177.1520 and NSF-51 standards the Clearforce hose is suitable for food and beverage dispensing powdered food manufacturing water and bilge lines washdown hose and in-plant air and water service. It is also effective for spraying and conveying fertilizers and pesticides.

Additionally the hose maintains a temperature range from +15deg;F to +150deg;F and has a minimum bend radius of 2 inches. Designed for compatibility with hose barbs hose clamps and crimp ferrules it ensures seamless integration into your existing systems.

MPN: H28508-300R

Supplier Part Number: H28508-300R

Specifications

Abrasion Resistance
28
Application
For food and beverage dispensing, powdered food manufacturing, water and bilge lines, washdown hose, in-plant air and water service and spraying and conveying fertilizers and pesticides.
Color
Clear
Construction
Extruded
Cover Material
PVC
Dash Size
-8
Brand
Danfoss (IGS)
Brand
Danfoss Power Solutions
Pack Size
1.00
UOM
FT
I.D.
0.5 in
Lay Line Style
Ink Jet
Maximum Working Pressure
200
Minimum Bend Radius
2
Minimum Bend Radius
2
Minimum Working Temperature
15
O.D.
0.75 in
Package Qty.
300
Reinforcement Material
Fiber
Supplier Part Number
H28508-300R
Tube Material
Polyvinyl Chloride (PVC)
Alternate Part Numbers
Alternate Part Number C1KW14, Alternate Part Number H28508, Alternate Part Number MINO-00115X00603
Product Weight
0.06 lbs

Related Documents

Similar Products

Model Number I.D. O.D. Maximum Working Pressure Minimum Bend Radius Package Qty. Price Action
Clearforce Reinforced Standard Duty PVC Hose, 0.45 Inch OD, 0.25 Inch ID, Up To 250.00 PSI

H28504-125R Clearforce Reinforced PVC Hose

0.25 in

0.45 in

250

1

125

Clearforce Reinforced Standard Duty PVC Hose, 0.59 Inch OD, 0.38 Inch ID, Up To 225.00 PSI

H28506-300R Clearforce Reinforced PVC Hose

0.38 in

0.59 in

225

1.25

300

Clearforce Reinforced Standard Duty PVC Hose, 0.75 Inch OD, 0.50 Inch ID, Up To 200.00 PSI

H28508-300R Clearforce Reinforced PVC Hose

0.5 in

0.75 in

200

2

300

Clearforce Reinforced Standard Duty PVC Hose, 0.88 Inch OD, 0.63 Inch ID, Up To 200.00 PSI

H28510-300R Clearforce Reinforced PVC Hose

0.625 in

0.875 in

200

2.5

300

Clearforce Reinforced Standard Duty PVC Hose, 1.03 Inch OD, 0.75 Inch ID, Up To 150.00 PSI

H28512-300R Clearforce Reinforced PVC Hose

0.75 in

1.031 in

150

2.5

300

Clearforce Reinforced Standard Duty PVC Hose, 1.31 Inch OD, 1.00 Inch ID, Up To 125.00 PSI

H28516-200R Clearforce Reinforced PVC Hose

1 in

1.313 in

125

3.5

200

Clearforce Reinforced Standard Duty PVC Hose, 1.69 Inch OD, 1.25 Inch ID, Up To 100.00 PSI

H28520-100 Clearforce Reinforced PVC Hose

1.25 in

1.688 in

100

100

Clearforce Reinforced Standard Duty PVC Hose, 1.94 Inch OD, 1.50 Inch ID, Up To 100.00 PSI

H28524-100 Clearforce Reinforced PVC Hose

1.5 in

1.938 in

100

100

Product Questions & Answers (3)

Question by: Lyle W on Jul 26, 2025, 6:03 AM
hose says it goes up to 200 PSI, is that enough for running air lines in a shop setting, or is this more of a light-duty thing?
Answer by: Customer Support on Jul 27, 2025, 9:49 AM
For in-plant air service, 200 PSI is a solid working pressure rating and puts it well above what most shop air systems actually run. The fiber reinforcement is what bumps it past standard PVC hose, so it holds up better under pressure without getting stiff or kinking on you. Just keep in mind the temperature range tops out at 150 degrees F, so if your lines run near heat sources or get baked in direct sun for long stretches, that's worth accounting for.
Question by: Jerry B on Aug 26, 2025, 8:13 AM
Wondering if this hose will hold up to spraying fertilizers in my yard?
Answer by: Customer Support on Aug 27, 2025, 10:18 AM
This Clearforce hose can handle spraying and conveying fertilizers and pesticides, along with a range of other applications. It's also compliant with FDA and NSF standards for food and beverage use, so it's pretty versatile.
Question by: Bobby H on Oct 13, 2025, 8:51 AM
need a clear hose for a sight gauge and drain line. is this the one with the fiber in it, or is it just plain pvc
Answer by: Customer Support on Oct 14, 2025, 11:15 AM
Clearforce is a clear PVC hose with fiber reinforcement, so you get visibility plus added strength compared to a non-reinforced clear PVC tube. It’s commonly used for drain lines and sight gauges, along with air lines and potable water transfer.
