1/2 Indl Nipple 3/8 M-NPTF, Steel 850497

Description & Features

This steel industrial nipple features 1/2 in. industrial nipple to 3/8 in. male NPTF connections.

The 1/2 Indl Nipple 3/8 M-NPTF, Steel 850497 is manufactured by Dixon Valve & Co.

SKU: D4M3

Supplier Part Number (MPN): D4M3

Alternate Part Numbers: MI-02075344, MINO-00647F29942

Brand DIXON	Connection Size 1 1/2 in	Connection Size 2 3/8 in	Connection Type MNPT, Quick-Disconnect	Connection Type 1 Quick Disconnect	Connection Type 2 Male NPTF	Dimensions 0.87 in OD x 2.19 in L	Finish Trivalent Chrome-Plated	Fitting Type Plug	Hex Size 3/4 in	Material Steel	Material Construction Steel	Maximum Operating Pressure 500 psi	Operating Temperature -40 to 250 deg F	Series DF Series	Thread Size 3/8-18

Question by: Phil T on May 23, 2025, 8:38 PM

So this is a 1/2 inch nipple that goes down to 3/8? Just want to make sure I'm reading it right.

Answer by: Customer Support on May 25, 2025, 5:37 PM

That's correct. This steel nipple has a 1/2 inch industrial nipple connection on one side and a 3/8 inch male NPTF connection on the other.
