DG4S4-01 50 Series Danfoss / Eaton Coils

Designed as older-style direct acting air gap solenoids, these coils are intended as replacement parts for legacy equipment, new applications should reference the Wet Armature 60 Series instead. The DG4S4-01 50 Series Danfoss / Eaton Coils feature internally rectified circuitry, a compact form factor, and are rated for continuous duty across mobile and industrial environments including harvesters and refuse haulers. Viton® seals are standard across the line.

Maximum operating pressure is 3,000 PSI at ports P, A, and B, with port T rated to 1,000 PSI. Maximum flow rates depend on the spool and spring combination selected in conjunction with the coil. Standard mounting uses four 1/4-20 x 1-1/2 Grade 8 socket head cap screws torqued to 112 lb.in. maximum with lubricated threads. Detented models require horizontal mounting along the longitudinal axis; all other configurations may be mounted in any position. These valves are available in a wide range of configurations beyond those listed in the standard catalog.

SKU: 195053

Supplier Part Number (MPN): 195053

Alternate Part Numbers: C1EM28
