main product photo

E-Z Clip Series Fitting, 5/8-18 Female O-Ring (Short Pilot), -08 Hose, 90 deg Elbow

Ask A Question

Description & Features

The Danfoss Power Solutions (II LLC Aeroquip) E-Z Clip Series Fitting is engineered for specialized applications requiring reliable and secure hose connections. This 90-degree elbow fitting features a 5/8-18 female O-ring (short pilot) and is designed for use with -08 hoses.

Durability and performance are ensured by the precise design eliminating guesswork leaks and the need for power tools. The fitting is easy to install even in confined spaces. Compatible with refrigeration or A/C systems the ergonomic design facilitates straightforward insertion and secure clipping.

Featuring robust materials this fitting is essential for secure and efficient fluid conveyance in specialized settings. Note that E-Z Clip components are designed for single use and should not be reused to maintain system integrity.

MPN: FJ5985-0608S

Supplier Part Number: FJ5985-0608S

Specifications

Brand
Danfoss
a Dimensions
3.33 in
Compatible Hose ID
1/2 in
Connection Size 1
1/2 in
Connection Size 2
3/8 in
Connection Type
Female Tube, Hose
Connection Type 1
Hose
Connection Type 2
Female Tube O-ring Short Pilot
Construction Style
Reusable
Cut-Off Factor
1.79 in
d Dimensions
1.79 in
Dimensions
3.33 in L x 0.75 in W x 2.21 in H
Drop Dimensions
1.38 in
End Gender 1
Female
End Gender 2
Male
End Size 1
5/8 in
End Size 2
1/2 in
Finish
Zinc-Plated
Fitting Type
90 deg Elbow
For Use With
E-Z Clip System A/C Refrigeration GH134 Series Hoses
h Dimensions
1.38 in
Hex Size
3/4 in
Hose Dash Size
08
Inside Diameter
0.26 in
Material
Steel
Material Construction
Carbon Steel
Seal Material
HNBR
Seal Part If Included
1F40106-08
Series
FJ5985 Series
Sg 1 Cut The Hose
Cut the Hose to Proper Length. Be Sure the Cut is Made Square to the Hose Length
Sg 2 Slip On Two Clips
Install Two Proper-Sized Clips Onto the Cut End of the Hose
Sg 3 Oil The Nipple
Lubricate the Nipple with a Generous Amount of the Refrigeration or A/C System's Compressor Oil. This Must be Done to Lower the Force of Nipple Insertion
Sg 4 Insert The Nipple Into The Hose
Insert the Nipple into the Hose. There Should be No Gap Between the End of the Hose and the Shoulder on the Nipple. Avoid Kinking or Damaging the Hose While Inserting Nipple
Sg 5 Snap On The Cage
Snap the Cage into the Groove on the Nipple. When the Cage Has Been Correctly Installed in the Cage Groove, the Cage Will be Able to Rotate in the Groove
Sg 6 Slide The Clips
Slide the Clips Over the Cage Arms and into the Channels on Each Arm
Sg 7 Close The Clips
Use the FT1357 Clip Closing Pliers to Close the Clips. The Pliers Should be Positioned Squarely on the Clip Connection Points and Should Remain Square During the Closing of the Clip
Sg Caution
Failure to Follow these Assembly Instructions and/or the Use of Aeroquip® Hose with Fittings Supplied by Other Manufacturers May Result in Unreliable and Unsafe Hose Assemblies, Which May Result in Sudden or Unintended Escape of Refrigerant Gases. Persona
Sg Material
Clip Closing Pliers (FT1357), Guillotine Blade (FT1356) or Equivalent Cutting Tool, Refrigerant Oil Compatible with Refrigeration or A/C System. GH134 Multi-Refrigerant Hose, Appropriately Sized Clips (2 per Fitting) and Cage, Nipple Assembly (The (2) Bla
Thread Sealant
Without Thread Sealant
Thread Size
5/8-18
Thread Type
UNF

Similar Products

Model Number Thread Size Hose Dash Size d Dimensions h Dimensions Price Action
E-Z Clip Series Fitting, 5/8-18 Female O-Ring (Short Pilot), -06 Hose, 90 deg Elbow

FJ5985-0606S E-Z Clip Series Short Pilot 90 Elbow

5/8-18

06

1.79 in

1.38 in

E-Z Clip Series Fitting, 3/4-16 Female O-Ring (Short Pilot), -08 Hose, 90 deg Elbow

FJ5985-0808S E-Z Clip Series Short Pilot 90 Elbow

3/4-16

08

2.23 in

1.62 in

E-Z Clip Series Fitting, 3/4-16 Female O-Ring (Short Pilot), -10 Hose, 90 deg Elbow

FJ5985-0810S E-Z Clip Series Short Pilot 90 Elbow

3/4-16

10

2.23 in

1.62 in

E-Z Clip Series Fitting, 7/8-14 Female O-Ring (Short Pilot), -12 Hose, 90 deg Elbow

FJ5985-1012S E-Z Clip Series Short Pilot 90 Elbow

7/8-14

12

2.67 in

1.89 in

E-Z Clip Series Fitting, 7/8-14 Female O-Ring (Short Pilot), -10 Hose, 90 deg Elbow

FJ5985-1010S E-Z Clip Series Short Pilot 90 Elbow

7/8-14

10

2.67 in

1.89 in

E-Z Clip Series Fitting, 1-1/16-14 Female O-Ring (Short Pilot), -12 Hose, 90 deg Elbow

FJ5985-1212S E-Z Clip Series Short Pilot 90 Elbow

1-1/16-14

12

3.16 in

2.56 in

Product Questions & Answers (3)

Question by: Rusty J on Jul 21, 2025, 8:04 PM
Will this fitting work with a standard -08 hose?
Answer by: Customer Support on Jul 23, 2025, 8:57 AM
It sure will. This E-Z Clip fitting is designed for use with a -08 size hose.
Question by: Bobby A on Jun 10, 2025, 8:38 PM
does this fitting work for A/C hose assemblies or is it strictly for hydraulic lines?
Answer by: Customer Support on Jun 12, 2025, 11:32 AM
Refrigeration and A/C systems are exactly what this fitting is built around. The nipple comes pre-installed with two black O-rings made from a specific rubber compound suited for those environments, and the assembly process calls for refrigeration or A/C compressor oil during installation. It is not a general-purpose hydraulic fitting. Pair it with GH134 Multi-Refrigerant hose and the appropriately sized clips and cage, and you have got a connection built for that kind of system.
Question by: Troy O on Nov 1, 2025, 8:14 PM
got a -08 hose and need a 90 to tuck it in tight. is this the short pilot female o-ring one with 5/8-18 threads?
Answer by: Customer Support on Nov 3, 2025, 6:36 AM
You’re looking at a 90 degree elbow E-Z Clip fitting for -08 hose with a 5/8-18 female O-ring seal end using the short pilot style.
