Aeroquip Hose 4-SPRL TUFFCOAT

Description & Features

Designed for high-pressure hydraulic system service with petroleum and water-based fluids the Aeroquip Hose 4-SPRL TUFFCOAT by Danfoss/Eaton is engineered to withstand harsh conditions. It features a robust synthetic rubber cover and a 6-spiral wire reinforcement providing superior construction that ensures durability and long-lasting performance.

This hydraulic spiral hose meets SAE 100R15 and ISO 18752-DC performance standards making it a reliable choice for general industrial applications. The hose's premium abrasion resistance and 1 000 000 impulse cycle life further ensure its dependability.

Certified by DNV USCG MSHA and ABS this conductive hose offers premium safety and compliance. It has a minimum bend radius of 5.31 inches and operates efficiently within temperatures as low as -40 degrees. Aeroquip Hose 4-SPRL TUFFCOAT is an optimal solution for maintaining the highest pressure requirements in demanding environments.

Supplier Part Number: EC600-12

Specifications

Abrasion Resistance 28	Application High pressure hydraulic system service with petroleum and water-based fluids, for general industrial service	Certifications SAE 100R15\|ISO 18752-DC Performance	Color Black	Compliances DNV\|USCG\|MSHA Approved\|ABS Certified	Conductivity 30	Construction 6 Spiral	Cover Material Synthetic Rubber	Dash Size -12	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Features Maximum durability under harsh operating conditions\|Robust construction able to withstand highest pressures\|System engineered to extend hose assembly life	ICC Hoses and Flexible Tubes	Impulse Cycle Life 1000000 cycle	Language English	Lay Line Style Transfer Tape	Minimum Bend Radius 5.31	Minimum Bend Radius 5.31	Minimum Working Temperature -40	Net Pack Quantity Units FT	NMFC 70	Product Width 1.31	Qualified Hose Fittings 1W, 4S, 6S	Reinforcement Material Wire	Sub Brand None	Supplier Part Number EC600-12	Tube Material Synthetic Rubber	Product Weight 2.00 lbs

Product Questions & Answers (2)

Question by: Janet W on Jun 22, 2025, 8:48 PM

What kind of hydraulic fluids can this hose handle? Just petroleum-based stuff?

Answer by: Customer Support on Jun 24, 2025, 7:10 AM

It's designed for high-pressure hydraulic systems using both petroleum and water-based fluids.

Question by: Hubert G on Sep 13, 2025, 5:51 PM

got a line that sees both oil and water-glycol. is this hose meant for that kind of mix-up?

Answer by: Customer Support on Sep 15, 2025, 6:16 AM

For high-pressure hydraulic service, it is built to handle petroleum-based fluids and water-based fluids, so it fits systems that run either type.
