Designed for hydraulic systems handling petroleum and water glycol base fluids, this -6 dash size hose delivers reliable performance under demanding pressure conditions. The Aeroquip DYNAMAX Hose 3/8 IN is built with a synthetic rubber inner tube and cover, reinforced with a two-ply steel wire braid construction that meets EN857 2SC certification standards.
With a minimum bend radius of 1.65 inches and a rated operating range starting at -50°F, the hose maintains flexibility and integrity across a wide thermal range. The conductive construction supports static dissipation requirements common in industrial hydraulic circuits. Ink jet lay line marking aids in installation orientation and identification in the field.
SKU: EC881-6R250
Supplier Part Number (MPN): EC881-6R250
Alternate Part Numbers: EC881-6, EC881-6R250
Loading related products…
Specifications
Alternate Part Numbers
Alternate Part NumberEC881-6, Alternate Part Number EC881-6R250., Alternate Part Number MINO-00015X20131
Application
Hydraulic system with petroleum and water glycol base fluids.
Certifications
EN857 2SC
Class
WEB-ITEM
Color
Black
Conductivity
30
Construction
2-ply braid
Cover Material
Synthetic Rubber
Dash Size
-6
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
12.00
UOM
FT
Features
Maximum durability under harsh operating conditions|Robust construction able to withstand highest pressures|System engineered to extend hose assembly life
ICC
Hoses and Flexible Tubes
Language
English
Lay Line Style
Ink Jet
Minimum Bend Radius
1.65
Minimum Bend Radius
1.65
Minimum Working Temperature
-50
Product Width
0.68
Reinforcement Material
Steel Wire
Supplier Part Number
EC881-6R250
Tube Material
Synthetic Rubber
Product Weight
0.28 lbs
Product Questions & Answers (1)
Question by: Ricky T on May 15, 2025, 9:07 PM
What kind of hydraulic fluid does this hose work with?
Answer by: Customer Support on May 17, 2025, 6:23 AM
It's designed for hydraulic systems that use petroleum and water glycol base fluids.
