Nylon Air Brake Tubing, Black, 0.31 Inch OD, 0.04 Inch Wall Thickness, 500 Feet Per Pack

Description & Features

Designed for truck and trailer air brake systems auxiliary air systems and air brake harness assemblies this product is ideal for various applications that require reliable and durable tubing. Constructed from extruded polyamide with UV stabilization it ensures long-lasting performance in harsh environments.

The tubing has a 0.31-inch outer diameter and a 0.04-inch wall thickness offering premium abrasion resistance. Engineered to meet SAE J844 J1131 J2494-3 DOT-FMVSS 106 standards it guarantees superior quality and safety compliance.

Thanks to its enhanced flexibility and improved flow performance it outperforms traditional rubber and other nylon tubing. Its ink-jet lay line style allows for easy identification and traceability.

With a minimum bend radius of 1.13 inches the tubing provides ease of installation and versatility in various configurations. It operates effectively within a temperature range of -65deg;F to 200deg;F making it suitable for both extreme cold and hot conditions.

MPN: 4245-0520-0500

Supplier Part Number: 4245-0520-0500

This black air brake tubing is available in packs of 500 feet ensuring sufficient length for extensive industrial projects.

Specifications

Abrasion Resistance 28	Application Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies.	Color Black	Construction Extruded	Cover Material UV Stabilized	Dash Size -5	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM FT	I.D. 0.23 in	Lay Line Style Ink Jet	Minimum Bend Radius 1.13	Minimum Bend Radius 1.13	Minimum Working Temperature -40	O.D. 0.313 in	Package Qty. 500	Reinforcement Material Polyamide	Supplier Part Number 4245-0520-0500	Tube Material Polyamide	Type A	Wall Thickness 0.04	Alternate Part Numbers Alternate Part Number C1MJ91, Alternate Part Number MINO-00803X01513	Product Weight 0.05 lbs

Similar Products

Model Number	Type	O.D.	Wall Thickness	I.D.	Minimum Bend Radius	Color	Package Qty.
3270-0610-0100 Eclipse / Solstice Air Brake Tubing	B	0.375 in	0.06	0.25 in	1.5	Black	100
3270-0610-0500 Eclipse / Solstice Air Brake Tubing	B	0.375 in	0.06	0.25 in	1.5	Black	500
3270-0612-0500 Eclipse / Solstice Air Brake Tubing	B	0.375 in	0.06	0.25 in	1.5	Red	500
3270-0613-0500 Eclipse / Solstice Air Brake Tubing	B	0.375 in	0.06	0.25 in	1.5	Orange	500
3270-0614-0500 Eclipse / Solstice Air Brake Tubing	B	0.375 in	0.06	0.25 in	1.5	Yellow	500
3270-0615-0500 Eclipse / Solstice Air Brake Tubing	B	0.375 in	0.06	0.25 in	1.5	Green	500
3270-0616-0500 Eclipse / Solstice Air Brake Tubing	B	0.375 in	0.06	0.25 in	1.5	Blue	500
3270-0810-0100 Eclipse / Solstice Air Brake Tubing	B	0.5 in	0.06	0.38 in	2	Black	100
3270-0810-0500 Eclipse / Solstice Air Brake Tubing	B	0.5 in	0.06	0.38 in	2	Black	500
3270-08104 Eclipse / Solstice Air Brake Tubing	B	0.5 in	0.06	0.38 in	2	Black	1500
3270-0812-0500 Eclipse / Solstice Air Brake Tubing	B	0.5 in	0.06	0.38 in	2	Red	500
3270-08124 Eclipse / Solstice Air Brake Tubing	B	0.5 in	0.06	0.38 in	2	Red	1500
3270-0815-0500 Eclipse / Solstice Air Brake Tubing	B	0.5 in	0.06	0.38 in	2	Green	500
3270-1010-0250 Eclipse / Solstice Air Brake Tubing	B	0.625 in	0.09	0.44 in	2.5	Black	250
3270-10103 Eclipse / Solstice Air Brake Tubing	B	0.625 in	0.09	0.44 in	2.5	Black	750
3270-1012-0250 Eclipse / Solstice Air Brake Tubing	B	0.625 in	0.09	0.44 in	2.5	Red	250
3270-1013-0250 Eclipse / Solstice Air Brake Tubing	B	0.625 in	0.09	0.44 in	2.5	Orange	250
3270-1015-0250 Eclipse / Solstice Air Brake Tubing	B	0.625 in	0.09	0.44 in	2.5	Green	250
3270-1016-0250 Eclipse / Solstice Air Brake Tubing	B	0.625 in	0.09	0.44 in	2.5	Blue	250
3270-1210-0250 Eclipse / Solstice Air Brake Tubing	B	0.75 in	0.09	0.57 in	3	Black	250
3270-1215-0250 Eclipse / Solstice Air Brake Tubing	B	0.75 in	0.09	0.57 in	3	Green	250
4245-0220-1000 Eclipse / Solstice Air Brake Tubing	A	0.125 in	0.02	0.08 in	1.25	Black	1000
4247-0410-0100 Eclipse / Solstice Air Brake Tubing	A	0.25 in	0.04	0.17 in	1	Black	100
4247-0410-1000 Eclipse / Solstice Air Brake Tubing	A	0.25 in	0.04	0.17 in	1	Black	1000
4247-0412-1000 Eclipse / Solstice Air Brake Tubing	A	0.25 in	0.04	0.17 in	1	Red	1000
4247-0413-1000 Eclipse / Solstice Air Brake Tubing	A	0.25 in	0.04	0.17 in	1	Orange	1000
4247-0414-1000 Eclipse / Solstice Air Brake Tubing	A	0.25 in	0.04	0.17 in	1	Yellow	1000
4247-0415-1000 Eclipse / Solstice Air Brake Tubing	A	0.25 in	0.04	0.17 in	1	Green	1000
4247-0416-1000 Eclipse / Solstice Air Brake Tubing	A	0.25 in	0.04	0.17 in	1	Blue	1000

Product Questions & Answers (2)

Question by: Scott M on Jul 19, 2025, 9:25 PM

What's the smallest circle I can bend this tubing into without messing it up?

Answer by: Customer Support on Jul 21, 2025, 8:57 AM

The minimum bend radius for this tubing is 1.13 inches. Trying to bend it tighter than that could cause kinks or damage.

Question by: Tony W on Jun 17, 2025, 11:29 AM

tubing rated for cold weather use? got rigs sitting outside all winter and need something that ain't gonna crack on me

Answer by: Customer Support on Jun 19, 2025, 6:45 AM

Rated from -65°F up to 200°F, so hard freezes won't be an issue for this tubing. The extruded polyamide construction holds up in temperature extremes better than standard rubber alternatives, and the UV stabilization helps it resist breakdown from sun exposure during warmer months too. For outdoor fleet use in cold climates, it's a solid fit.
