Danfoss / Eaton;Danfoss / Eaton;Coolant Hose;EH22620;Coolant Hose;Working Pressure ;Inside diameter 1.25 IN;Outside diameter 1.62 IN;Product length 36 IN

Description & Features

Constructed with a silicone tube and silicone cover, this 4-ply coolant hose is built to handle the thermal demands of engine cooling circuits, with a rated temperature range starting at -54°C. The polyester reinforcement contributes to structural integrity under pressure, while the premium abrasion-resistant cover supports durability in under-hood environments.

The Danfoss / Eaton EH22620 Coolant Hose measures 1.25 IN inside diameter, 1.62 IN outside diameter, and 36 IN in length, a Dash -20 size suited for engine coolant routing applications. Blue in color with an ink jet lay line, it meets SAE J20 Class A and SAE J20R1 Class A certifications. The hose is also conductive, making it compatible with applications where static dissipation is a consideration.

SKU: EH22620

Supplier Part Number (MPN): EH22620

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00925X12421	Application Coolant engine.	Certifications SAE J20 Class A\|SAE J20R1 Class A	Color Blue	Conductivity 30	Construction 4 Ply	Cover Material Silicone	Dash Size -20	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM FT	Features Highly abrasion resistant cover\|Small number of hoses for many fuel options\|Proven reliability with high temperature resistance	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Working Temperature -54	Product Width 1.62	Reinforcement Material Polyester	Sub Brand None	Supplier Part Number EH22620	Tube Material Silicone	Product Weight 1.79 lbs

Product Questions & Answers (1)

Question by: Steve H on Jun 8, 2025, 8:40 PM

trying to swap out a short coolant hose, is this one 1 1/4 inch inside and 36 inches long?

Answer by: Customer Support on Jun 10, 2025, 8:50 AM

The EH22620 is a 36 inch hose with a 1.25 inch inside diameter and a 1.62 inch outside diameter. It is also a Dash -20 size.
