Danfoss / Eaton Silicone Hose

Description & Features

Rated to SAE J20 Class A and SAE J20R1 Class A standards, the Danfoss / Eaton Silicone Hose is built for demanding coolant and engine applications where temperature extremes and abrasion resistance are primary concerns. The silicone inner tube and silicone cover are reinforced with four-ply polyester construction, providing structural integrity across a wide service temperature range with a minimum working temperature of -54°C.

The blue cover features a premium abrasion-resistant finish and conductive properties, with lay line marking applied via ink jet. Sized at Dash -26, this hose is designed to accommodate multiple fuel and coolant configurations with a reduced need for multiple hose variants across an application. The Aeroquip brand association confirms compatibility within established Eaton product families.

SKU: EH22626

Supplier Part Number (MPN): EH22626

Specifications

Brand Aeroquip® by Danfoss	Abrasion Resistance Premium	Color Blue	Conductivity Conductive	Construction 4-Ply	Cover Material Silicone	Dash Size 26	Domestic/Import Domestic	Hose Type Braided, Conductive	Inside Diameter 1-5/8 in	Lay Line Style Inkjet	nmfc 70	Nominal Size #26	Reinforcement Material Polyester	Segment Code C	Series EH226 Series	Tube Material Silicone

Similar Products

Model Number	Nominal Size	Inside Diameter
EH22610	10	5/8 in
EH22612	#12	3/4 in
EH22614	#14
EH22616	#16	1 in
EH22618	#18	1.13 in
EH22624	#24	1-1/2 in
EH22628	#28	1-3/4 in
EH22632	#32
EH22636	#36
EH22638	#38
EH22644	#44
EH22648	#48	3 in
EH22656	#56
EH22660	#60
EH22664	#64
EH22672	#72
EH22680	#80
EH22688	#88
EH22696	#96
