Danfoss / Eaton Silicone Hose

Description & Features

Engineered for demanding engine coolant applications, this Danfoss / Eaton Silicone Hose is built around a four-ply construction with a silicone inner tube, polyester reinforcement, and a silicone outer cover rated for premium abrasion resistance. The blue cover is conductive and features an ink jet lay line for easy identification in the field.

Rated to a minimum working temperature of -54°C, this hose is well suited for high-temperature engine environments where thermal stability is critical. It meets SAE J20R1 Class A and SAE J20 Class A certifications, confirming its suitability for engine coolant service across a broad range of fuel system configurations. The dash -40 size accommodates high-flow coolant routing in heavy-duty engine applications.

SKU: EH22640

Supplier Part Number (MPN): EH22640

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00015X09470	Application Coolant engine.	Certifications SAE J20R1 Class A\|SAE J20 Class A	Color Blue	Conductivity 30	Construction 4 Ply	Cover Material Silicone	Dash Size -40	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Features Highly abrasion resistant cover\|Small number of hoses for many fuel options\|Proven reliability with high temperature resistance	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Working Temperature -54	Net Pack Quantity Units FT	NMFC 70	Product Width 2.87	Reinforcement Material Polyester	Sub Brand None	Supplier Part Number EH22640	Tube Material Silicone	Product Weight 2.36 lbs

Product Questions & Answers (2)

Question by: Keith M on Oct 17, 2025, 12:36 PM

What size is this hose exactly? I need to make sure it'll fit my engine coolant lines.

Answer by: Customer Support on Oct 19, 2025, 8:42 AM

This hose comes in a -40 dash size, which should be suitable for high-flow coolant routing in heavy-duty engine applications.

Question by: Scott S on Apr 22, 2025, 9:26 AM

got a coolant line that sees a lot of heat, is this hose built for that kind of service?

Answer by: Customer Support on Apr 24, 2025, 6:52 AM

For hot engine coolant runs, this hose is a good fit. It is made for engine coolant applications and uses a 4 ply build with a silicone tube and silicone cover for thermal stability, plus it is rated down to a minimum working temperature of -54°C.
