Hose Silicone SAE J20 R14 Ply Coolant

Description & Features

Designed for engine coolant service, this blue silicone hose meets SAE J20 Class A and SAE J20R1 Class A certification requirements, making it a reliable choice for demanding under-hood thermal environments. The silicone tube and cover are supported by a four-ply polyester reinforcement, providing structural integrity across a wide operating temperature range with a minimum working temperature of -54°C.

The Hose Silicone SAE J20 R14 Ply Coolant carries a premium abrasion-resistant cover that holds up well in high-friction routing conditions. Conductive construction helps manage static charge in fuel and coolant circuits. Printed with an ink jet lay line, the hose is part of the Aeroquip EH226 Series and accommodates a broad range of coolant system configurations in a single dash size -60 offering.

SKU: EH22660

Supplier Part Number (MPN): EH22660

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00015X09478	Application Coolant engine.	Certifications SAE J20 Class A\|SAE J20R1 Class A	Color Blue	Conductivity 30	Construction 4 Ply	Cover Material Silicone	Dash Size -60	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM FT	Features Highly abrasion resistant cover\|Small number of hoses for many fuel options\|Proven reliability with high temperature resistance	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Working Temperature -54	Net Pack Quantity Units FT	NMFC 70	Product Width 4.12	Reinforcement Material Polyester	Sub Brand None	Supplier Part Number EH22660	Tube Material Silicone	Product Weight 4.59 lbs

Product Questions & Answers (1)

Question by: Larry M on Apr 29, 2025, 5:21 PM

Wondering if this hose is gonna hold up under the hood of my truck? Gets pretty hot here in the summer.

Answer by: Customer Support on May 1, 2025, 4:30 PM

Designed for demanding thermal environments, this silicone hose is made to withstand high temperatures. Its premium abrasion-resistant cover also holds up well in high-friction routing conditions, so it should be a reliable choice for your truck.
