Danfoss / Eaton Danfoss / Eaton Coolant Hose EH22680 Coolant Hose Working Pressure Inside diameter 5 IN Outside diameter 5.37 IN Product length 36 IN

Description & Features

Built for high-temperature coolant service, this 4-ply silicone hose from Eaton Aeroquip is designed to handle demanding engine cooling applications with reliable performance across a wide temperature range, rated down to -54°C on the low end. The Danfoss / Eaton Coolant Hose EH22680 measures 5 inches inside diameter with a 5.37-inch outside diameter and is supplied in a 36-inch length, making it suitable for large-bore engine cooling circuits.

Construction features a silicone inner tube and silicone cover reinforced with polyester, providing a premium level of abrasion resistance suited for environments where hose routing and contact wear are concerns. The blue cover is electrically conductive and printed with an ink jet lay line for orientation reference during installation. This hose carries SAE J20R1 Class A and SAE J20 Class A certifications, confirming compliance with recognized standards for automotive and industrial coolant hose service.

SKU: EH22680

Supplier Part Number (MPN): EH22680

Specifications

Abrasion Resistance 28	Application Coolant engine.	Certifications SAE J20R1 Class A\|SAE J20 Class A	Color Blue	Conductivity 30	Construction 4 Ply	Cover Material Silicone	Dash Size -80	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Features Highly abrasion resistant cover\|Small number of hoses for many fuel options\|Proven reliability with high temperature resistance	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Working Temperature -54	Net Pack Quantity Units FT	NMFC 70	Product Width 5.37	Reinforcement Material Polyester	Sub Brand None	Supplier Part Number EH22680	Tube Material Silicone	Product Weight 6.38 lbs

Product Questions & Answers (2)

Question by: Merle R on Feb 9, 2026, 5:59 PM

What temp range can this hose handle?

Answer by: Customer Support on Feb 11, 2026, 6:17 AM

This hose is rated down to -54°C on the low end, so it can handle some pretty cold engine cooling applications.

Question by: Marvin B on Oct 15, 2025, 9:23 PM

got a big coolant line on a diesel, is this hose actually 5 inch inside and how long is the piece?

Answer by: Customer Support on Oct 17, 2025, 1:58 PM

The inside diameter is 5 inches, the outside diameter is 5.37 inches, and it comes as a 36 inch length.
