Danfoss / Eaton;Danfoss / Eaton;Coolant Hose;EH22696;Coolant Hose;Working Pressure ;Inside diameter 6 IN;Outside diameter 6.37 IN;Product length 36 IN

Description & Features

This Eaton Industrial Hose is a Danfoss / Eaton Coolant Hose with a 6 inch inside diameter and 6.37 inch outside diameter, with a length of 36 inches. Designed for coolant engine applications, it features a highly abrasion resistant silicone cover with a 4-ply polyester reinforcement.

The hose meets SAE J20R1 Class A and SAE J20 Class A certifications and is constructed with a conductive silicone tube material. Its blue cover offers premium abrasion resistance and proven reliability with high temperature resistance.

SKU: EH22696

Supplier Part Number (MPN): EH22696

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00015X09484	Application Coolant engine.	Certifications SAE J20R1 Class A\|SAE J20 Class A	Color Blue	Conductivity 30	Construction 4 Ply	Cover Material Silicone	Dash Size -96	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Features Highly abrasion resistant cover\|Small number of hoses for many fuel options\|Proven reliability with high temperature resistance	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Working Temperature -54	Net Pack Quantity Units FT	NMFC 70	Product Width 6.37	Reinforcement Material Polyester	Sub Brand None	Supplier Part Number EH22696	Tube Material Silicone	Product Weight 7.43 lbs

Product Questions & Answers (2)

Question by: Warren H on Sep 5, 2025, 8:39 AM

Reckon this hose'll hold up okay in a coolant engine setup?

Answer by: Customer Support on Sep 6, 2025, 8:37 PM

This Eaton silicone hose is specifically designed for coolant engine applications, so it should be a good fit.

Question by: Brent J on May 31, 2025, 8:23 AM

got a 6 inch coolant line to replace, is this one actually 6 inch on the inside or is that outside?

Answer by: Customer Support on Jun 1, 2025, 3:20 PM

Inside diameter is 6 inches on this hose, and the outside diameter is 6.37 inches. The overall hose length is 36 inches.
