EPDM Double Wire Braid Aviation Ground Support Hose

Description & Features

Application	Aviation ground support equipment service with straight phosphate ester fluids (Skydrol LD4, Skydrol 500B, Hyjet IVA Plus). Please review the general guidelines for selection, installation and maintenance of hose assemblies starting on
Construction	EPDM tube, double wire braid reinforcement and green EPDM cover.
Note	Not designed for use with petroleum based fluids.
Temperature Range	-40°F. to +175°F.

Products

Model Number	Hose I.D.	Hose O.D.	Maximum Operating Pressure	Minimum Bend Radius	Reel Qty (ft)
FC693-04 EPDM Aviation Ground Support Hose	0.25	0.595	5000	4	Rolls Only
FC693-06 EPDM Aviation Ground Support Hose	0.38	0.75	4000	5	Rolls Only
FC693-08 EPDM Aviation Ground Support Hose	0.5	0.871	3500	7	Rolls Only

Product Questions & Answers (1)

Question by: Clint C on Aug 27, 2025, 1:00 PM

Will this hose hold up to Skydrol 500B without issues? Seen some hoses degrade quick with that stuff.

Answer by: Customer Support on Aug 29, 2025, 6:43 AM

This hose is specifically designed to handle straight phosphate ester hydraulic fluids like Skydrol 500B, so you shouldn't have any compatibility problems.
