Aeroquip ENGINE AIR Brake.25

Description & Features

Designed for demanding under-hood and brake system environments, the Aeroquip ENGINE AIR Brake.25 is a -5 dash size hose built to handle air, gasoline, fuel, lubricating oils, and coolants within a single, versatile platform. Its chlorinated polyethylene tube and dual-ply polyester and wire reinforcement work together to deliver dependable performance across a broad temperature range, with a minimum working temperature of -55°F and a tight minimum bend radius of 1 inch suited to routing in confined spaces.

The polyester cover provides premium abrasion resistance and conductive properties, making it appropriate for fuel-sensitive applications where static dissipation matters. Lay line marking is applied via ink wheel for clear identification. The hose is compatible with 100R5 reusable fittings and meets SAE J1402 ABS, DOT FMVSS 106 Type AII, DNV, and USCG compliance requirements, a combination that supports use in automotive, marine, and commercial vehicle fuel and brake systems.

SKU: FC350-05

Supplier Part Number (MPN): FC350-05

Specifications

Abrasion Resistance 28	Application Air, gasoline, fuel, lubricating oils and coolants.	Certifications SAE J1402\|ABS	Color Black	Compliances DOT FMVSS 106 Type AII\|DNV\|USCG	Conductivity 30	Construction 2-ply braid	Cover Material Polyester	Dash Size -5	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Features Highly abrasion resistant cover\|Small number of hoses for many fuel options\|Proven reliability with high temperature resistance	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Wheel	Minimum Bend Radius 1	Minimum Bend Radius 1	Minimum Working Temperature -55	Product Width 0.60	Qualified Hose Fittings 100R5 Reusable	Reinforcement Material Polyester and Wire	Sub Brand Aeroquip	Supplier Part Number FC350-05	Tube Material Chlorinated Polyethylene	Product Weight 0.52 lbs

Product Questions & Answers (1)

Question by: Dwayne S on Jul 13, 2025, 9:06 PM

So this hose handles gasoline and oil, but what about coolant?

Answer by: Customer Support on Jul 15, 2025, 7:52 AM

Yes, this Aeroquip hose is designed to handle air, gasoline, fuel, lubricating oils, and coolants. It's built to work in demanding under-hood and brake system environments.
