AEROQUIP HOSE

Description & Features

AEROQUIP HOSE with a -20 dash size, featuring a chlorinated polyethylene tube and a durable polyester cover. The hose is constructed with a 1 Ply Braid reinforcement of polyester and wire, offering premium abrasion resistance.

This black, conductive hose meets SAE J1402 and ABS certifications, and complies with USCG, DOT FMVSS 106 Type AII, and DNV standards. It is suitable for use with reusable, 100R5 qualified hose fittings. The hose has a minimum bend radius of 4.5 inches and can operate in temperatures as low as -55 degrees.

SKU: FC350-20-06000

Supplier Part Number (MPN): FC350-20-06000

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00015X10700	Certifications SAE J1402\|ABS	Class WEB-ITEM	Color Black	Compliances USCG\|DOT FMVSS 106 Type AII\|DNV	Conductivity 30	Construction 1 Ply Braid	Cover Material Polyester	Dash Size -20	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Wheel	Minimum Bend Radius 4.50	Minimum Bend Radius 4.5	Minimum Working Temperature -55	Product Width 1.53	Qualified Hose Fittings Reusable, 100R5	Reinforcement Material Polyester and Wire	Supplier Part Number FC350-20-06000	Tube Material Chlorinated Polyethylene	Product Weight 0.99 lbs

Product Questions & Answers (1)

Question by: Rex P on Aug 27, 2025, 8:16 PM

What kind of fittings work with this hose? I've got some reusable ones lying around.

Answer by: Customer Support on Aug 29, 2025, 6:13 AM

This hose is qualified for use with reusable, 100R5 hose fittings.
