Aeroquip Hose And Coil - Code

Description & Features

Designed for low pressure return line service in hydraulic systems, this Dash -4 rubber hose features a two-ply polyester braid reinforcement over an AQP inner tube, with an elastomer cover rated for premium abrasion resistance. The blue cover is conductive and carries a minimum bend radius of 2.5 inches, with a minimum working temperature of -40°F.

The Aeroquip Hose And Coil - Code meets both SAE 100R6 and EN854 Type R6 certifications, making it a reliable choice where standardized performance is required. Ink wheel lay line marking runs along the length for easy identification and routing.

Built under the Aeroquip brand by Danfoss/Eaton, this hose is engineered to extend assembly service life under demanding conditions without compromising flexibility at low temperatures.

SKU: FC466-04

Supplier Part Number (MPN): FC466-04

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00015X51110	Application Low pressure return lines in hydraulic systems.	Certifications EN854 Type R6\|SAE 100R6	Color Blue	Conductivity 30	Construction 2-ply braid	Cover Material Elastomer	Dash Size -4	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Features Maximum durability under harsh operating conditions\|Robust construction able to withstand highest pressures\|System engineered to extend hose assembly life	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Wheel	Minimum Bend Radius 2.50	Minimum Bend Radius 2.5	Minimum Working Temperature -40	Product Width 0.48	Reinforcement Material Polyester	Sub Brand Aeroquip	Supplier Part Number FC466-04	Tube Material AQP Inner tube	Product Weight 0.33 lbs

Product Questions & Answers (1)

Question by: Kent R on Oct 22, 2025, 7:42 PM

Would this hose work alright for the hydraulic return line on my tractor?

Answer by: Customer Support on Oct 24, 2025, 8:25 AM

It's designed for low-pressure return lines in hydraulic systems. As long as your tractor's return line operates within those parameters, it should work fine.
