Aeroquip TEXTILE Braid Hose

Description & Features

Eaton Aeroquip TEXTILE Braid Hose, featuring a one-ply braid construction and elastomer cover, is designed for low-pressure hydraulic return lines.

Constructed with a AQP inner tube and a polyester reinforcement material, this blue hose is MSHA approved and meets SAE 100R6 and EN854 Type R6 certifications. The Aeroquip TEXTILE Braid Hose provides maximum durability in demanding conditions and is engineered for extended service life.

This conductive hose has a minimum bend radius of 5 inches and can operate in temperatures as low as -40 degrees.

SKU: FC498-10

Supplier Part Number (MPN): FC498-10

Specifications

Abrasion Resistance 29	Application Low pressure return lines in hydraulic systems.	Certifications SAE 100R6\|EN854 Type R6	Color Blue	Compliances MSHA Approved	Conductivity 30	Construction 1 Ply Braid	Cover Material Elastomer	Dash Size -10	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Features Maximum durability under harsh operating conditions\|Robust construction able to withstand highest pressures\|System engineered to extend hose assembly life	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Wheel	Minimum Bend Radius 5	Minimum Bend Radius 5	Minimum Working Temperature -40	Product Width 0.91	Reinforcement Material Polyester	Sub Brand Aeroquip	Supplier Part Number FC498-10	Tube Material AQP Inner tube	Product Weight 0.63 lbs

Product Questions & Answers (2)

Question by: Neil G on Jan 22, 2026, 9:18 AM

Does this hose meet any kind of safety or industry certifications, or is it just a standard hydraulic hose?

Answer by: Customer Support on Jan 23, 2026, 3:17 PM

Certified to both SAE 100R6 and EN854 Type R6 standards, and it also carries MSHA approval, which matters if you're running equipment in mining environments. The one-ply polyester braid construction and AQP inner tube are built to hold up in low-pressure return line service without cutting corners on compliance.

Question by: Eddie C on Nov 17, 2025, 9:47 AM

got a hydraulic tank return line that sees light pressure, is this hose the right kind for that?

Answer by: Customer Support on Nov 18, 2025, 7:57 PM

For low-pressure hydraulic return lines, this Aeroquip textile braid hose is a good match. It is built with a one-ply polyester braid reinforcement and an elastomer cover, and it meets SAE 100R6 and EN854 Type R6.
