Aeroquip Hose And Coil - Code HC

Description & Features

Engineered for maximum durability, the Eaton Aeroquip Hose And Coil - Code HC is designed to withstand harsh operating conditions and the highest pressures. Featuring a 1-ply braided construction with wire reinforcement, this hose ensures robust performance and extended assembly life. It is specifically crafted for use with phosphate ester base fluids, providing reliable conductivity.

The hose is constructed with a green EPDM cover and tube, offering standard abrasion resistance. With a dash size of -16 and a minimum bend radius of 12 inches, it is ideal for applications requiring flexible routing and tight bends. The ink transfer lay line style and TTC qualified hose fittings further enhance its utility in demanding environments.

SKU: FC611-16

Supplier Part Number (MPN): FC611-16

Specifications

Abrasion Resistance 29	Application For use with phosphate ester base fluids.	Color Green	Conductivity 30	Construction 1 Ply Braid	Cover Material EPDM	Dash Size -16	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Features Maximum durability under harsh operating conditions\|Robust construction able to withstand highest pressures\|System engineered to extend hose assembly life	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Transfer	Minimum Bend Radius 12	Minimum Bend Radius 12	Minimum Working Temperature -40	Product Width 1.44	Qualified Hose Fittings TTC	Reinforcement Material Wire	Sub Brand Aeroquip	Supplier Part Number FC611-16	Tube Material EPDM	Product Weight 1.66 lbs

Product Questions & Answers (2)

Question by: Lance M on Jan 12, 2026, 11:21 AM

what's the minimum bend radius on this hose? got some tight routing to work around and need to know before I order

Answer by: Customer Support on Jan 13, 2026, 8:53 PM

Twelve inches is the minimum bend radius on this one. If your routing requires anything tighter than that, you'd want to look at a different hose. For most industrial setups with moderate bends, twelve inches gives you enough flexibility to work around most obstacles without stressing the assembly.

Question by: Pete K on Jul 18, 2025, 4:40 PM

got a system that runs phosphate ester fluid, is this the right hose material for that?

Answer by: Customer Support on Jul 20, 2025, 12:32 PM

For phosphate ester base fluids, the tube and cover on this hose are EPDM, and it is specifically called out for that fluid type. It is also listed as conductive, which is often important in those applications.
