Aeroquip MULTI / REFRIG Hose

Description & Features

Designed for air conditioning and refrigeration applications in bus and rail systems, this -12 dash size hose is built to SAE J2064 certification and compatible with multiple refrigerants, including R1234yf. The Aeroquip Multi / Refrig Hose features a chloroprene tube, EPDM cover, and single-ply wire braid reinforcement, with a conductive construction suited to demanding mobile HVAC environments.

Rated for a minimum working temperature of -40°C and a minimum bend radius of 3 inches, the hose supports up to 150,000 impulse cycles. The R1234yf effusion rate is 0.5 kg/m²/yr at 80°C. Compatible qualified fittings include the EJ5305, EJ5361, EJ5362, EJ5306, EJ5359, EJ5360, GA25126, GA25127, and GA25128 series, as well as factory-crimped options.

SKU: FC800-12

Supplier Part Number (MPN): FC800-12

Specifications

Abrasion Resistance Standard	Color Black	Construction 1-Wire Braided	Cover Material EPDM	Dash Size 12	Effusion Rate 0.5 kg/sq-m/yr at 80 deg C R1234yf Effusion	For Use With Reusable Hose Fittings	Hose Color Black	Hose Type Conductive	Impulse Cycle 150000	Impulse Cycle Life 150000	Inside Diameter 0.646 in	Lay Line Style Inkjet	Nominal Size #12	Package Form Bulk	Qualified Hose Fittings EJ5305, EJ5361, EJ5362, EJ5306, EJ5359, EJ5360, GA25126, GA25127, GA25128/Factory Crimped Fittings	Reinforcement 1-Wire Braided Brass-Plated Steel Wire	Reinforcement Material Brass-Plated Steel Wire	Resistance Abrasion	Resistance Properties Abrasion	Series FC800 Series	Tube Material Chloroprene

Product Questions & Answers (3)

Question by: Brent B on May 3, 2025, 2:21 PM

got a bus AC job and need -12 hose. is this one actually meant for that kind of setup?

Answer by: Customer Support on May 5, 2025, 7:09 AM

For bus and rail air conditioning and refrigeration work, this Aeroquip hose is built for that service and meets SAE J2064. It is a -12 dash size hose with a conductive construction intended for mobile HVAC environments.

Question by: Gene B on Jul 25, 2025, 7:10 AM

Running a fleet of transit buses and need to know if this hose'll hold up to R1234yf refrigerant. That stuff's been giving us fits with older hoses.

Answer by: Customer Support on Jul 26, 2025, 12:22 PM

R1234yf compatibility is built into this hose, not added as an afterthought. The FC800-12 is rated for it specifically, with an effusion rate of 0.5 kg/m²/yr at 80°C. That figure meets SAE J2064 requirements, which this hose is certified to. For transit bus AC systems running that refrigerant, it's a solid fit.

Question by: Wes S on Sep 23, 2025, 3:40 PM

What kind of systems is this hose good for?

Answer by: Customer Support on Sep 25, 2025, 9:54 AM

This Aeroquip hose is designed for air conditioning and refrigeration, specifically in bus and rail applications.
