Aeroquip MULTI / REFRIG Hose

Description & Features

Designed for air conditioning and refrigeration applications in bus and rail systems, this Dash -16 hose features a chloroprene tube, EPDM cover, and single-ply wire braid reinforcement. The conductive construction carries a minimum working temperature of -40°C and a rated impulse cycle life of 150,000 cycles.

The Aeroquip Multi / Refrig Hose meets SAE J2064 certification and is compatible with multiple refrigerants, including R1234yf, with an effusion rate of 0.5 kg/m²/yr at 80°C. Minimum bend radius is 3.5 inches. Compatible fittings include EJ5305, EJ5361, EJ5362, EJ5306, EJ5359, EJ5360, GA25126, GA25127, GA25128, or factory-crimped options.

SKU: FC800-16

Supplier Part Number (MPN): FC800-16

Specifications

Abrasion Resistance 29	Alternate Part Numbers Alternate Part Number MINO-00015X10978	Application Air conditioning and refrigeration, bus and rail AC.	Certifications SAE J2064	Color Black	Conductivity 30	Construction 1 Ply Braid	Cover Material EPDM	Dash Size -16	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Effusion Rate R1234yf Effusion: 0.5 kg/m²/yr at 80°C	Features Deliver performance and maximum uptime\|Hoses exceed SAE J2064\|Compatible with multiple refrigerants	ICC Hoses and Flexible Tubes	Impulse Cycle Life 150000 cycle	Language English	Lay Line Style Transfer Tape	Minimum Bend Radius 3.50	Minimum Bend Radius 3.5	Minimum Working Temperature -40	Product Width 1.24	Qualified Hose Fittings EJ5305, EJ5361, EJ5362, EJ5306, EJ5359, EJ5360, GA25126, GA25127, GA25128 or Factory crimped	Reinforcement Material Wire	Sub Brand None	Supplier Part Number FC800-16	Tube Material Chloroprene	Product Weight 1.47 lbs

Product Questions & Answers (3)

Question by: Curt M on Jul 7, 2025, 4:18 PM

Running a transit bus fleet and need to swap out the AC hose on a few units. This is a -16 dash size, right? And what fittings are we looking at for field installation?

Answer by: Customer Support on Jul 9, 2025, 3:35 PM

Correct, it's a Dash -16 hose. For field installation, compatible fittings include EJ5305, EJ5361, EJ5362, EJ5306, EJ5359, EJ5360, GA25126, GA25127, and GA25128. Factory-crimped options are also available if you'd rather go that route. Just make sure you're not bending it tighter than 3.5 inches minimum bend radius during routing or you risk compromising the hose integrity.

Question by: Lyle M on Sep 28, 2025, 8:10 AM

Reckon this hose'll hold up in the engine compartment of a railcar? Gets pretty hot in there.

Answer by: Customer Support on Sep 29, 2025, 4:16 PM

Designed specifically for air conditioning and refrigeration systems, this hose handles temperatures down to -40°C, making it suitable for the demands of bus and rail applications.

Question by: Cody H on Aug 6, 2025, 8:37 AM

got a tight spot to snake this line through, how tight can i bend the FC800-16 without kinking it

Answer by: Customer Support on Aug 7, 2025, 9:59 PM

For the Dash -16 Aeroquip Multi / Refrig hose (FC800-16), the minimum bend radius is 3.5 inches. Staying at or above that radius helps prevent kinks and keeps the reinforcement from getting stressed.
