Aeroquip MULTI / REFRIG Hose

Description & Features

Eaton Aeroquip MULTI / REFRIG Hose is designed for air conditioning and refrigeration applications, including bus and rail AC systems. This hose is compatible with multiple refrigerants and exceeds SAE J2064 standards.

Featuring a chloroprene tube and EPDM cover, this black, conductive hose offers standard abrasion resistance and delivers maximum uptime. It has a 6.5-inch minimum bend radius and has been tested to 150,000 impulse cycles. The Aeroquip MULTI / REFRIG Hose has an R1234yf effusion rate of 0.5 kg/m²/yr at 80°C. It is constructed with a 1-ply braid of wire reinforcement.

Qualified hose fittings include EJ5305, EJ5361, EJ5362, EJ5306, EJ5359, EJ5360, GA25126, GA25127, GA25128 or factory crimped.

SKU: FC800-24

Supplier Part Number (MPN): FC800-24

Specifications

Abrasion Resistance Standard	Color Black	Construction 1-Wire Braided	Cover Material EPDM	Dash Size 24	Effusion Rate 0.5 kg/sq-m/yr at 80 deg C R1234yf Effusion	For Use With Reusable Hose Fittings	Hose Color Black	Hose Type Conductive	Impulse Cycle 150000	Impulse Cycle Life 150000	Lay Line Style Inkjet	Nominal Size #24	Package Form Bulk	Qualified Hose Fittings EJ5305, EJ5361, EJ5362, EJ5306, EJ5359, EJ5360, GA25126, GA25127, GA25128/Factory Crimped Fittings	Reinforcement 1-Wire Braided Brass-Plated Steel Wire	Reinforcement Material Brass-Plated Steel Wire	Resistance Abrasion	Resistance Properties Abrasion	Series FC800 Series	Tube Material Chloroprene

Product Questions & Answers (1)

Question by: Todd B on Feb 8, 2026, 7:50 AM

What kind of fittings work with this hose?

Answer by: Customer Support on Feb 9, 2026, 7:49 PM

Qualified hose fittings for the Aeroquip MULTI / REFRIG Hose include EJ5305, EJ5361, EJ5362, EJ5306, EJ5359, EJ5360, GA25126, GA25127, GA25128, or factory crimped options.
