Designed for refined petroleum-based fluid service, the Aeroquip Bruiserhose is a Dash -6 hydraulic hose built to SAE 100R17 standards with a synthetic rubber inner tube, single-ply steel wire braid reinforcement, and a proprietary Bruiser outer cover rated for demanding industrial environments. The conductive construction supports static-dissipating applications, and the hose is rated for a minimum working temperature of -40°F with a minimum bend radius of 2.56 inches.
Certified to DNV and ABS standards and approved under MSHA IC-84/71, this hose is engineered for high-pressure hydraulic circuits where assembly longevity and cover durability are priorities. An impulse cycle life of 200,000 cycles reflects robust construction suitable for high-demand mobile and industrial equipment. The ink transfer lay line aids proper installation alignment, and compatibility is confirmed with Series 1A qualified fittings.
SKU: FC839B-06RL
Supplier Part Number (MPN): FC839B-06RL
|
Alternate Part Numbers
MINO-00015X11011
|
Application
Refined petroleum based fluids
|
Certifications
SAE 100R17
|
Color
Black
|
Compliances
DNV|ABS Certified|MSHA Approved|MSHA IC-84/71
|
Conductivity
30
|
Construction
1 Ply Braid
|
Cover Material
Bruiser
|
Dash Size
-6
|
Brand
Danfoss Power Solutions (II LLC Aeroquip)
|
Brand
Aeroquip
|
Pack Size
12.00
|
UOM
FT
|
Features
Maximum durability under harsh operating conditions|Robust construction able to withstand highest pressures|System engineered to extend hose assembly life
|
ICC
Hoses and Flexible Tubes
|
Impulse Cycle Life
200000 cycle
|
Language
English
|
Lay Line Style
Ink Transfer
|
Minimum Bend Radius
2.56
|
Minimum Bend Radius
2.56
|
Minimum Working Temperature
-40
|
Product Width
0.67
|
Qualified Hose Fittings
1A
|
Reinforcement Material
Steel
|
Sub Brand
Aeroquip
|
Supplier Part Number
FC839B-06RL
|
Tube Material
Synthetic Rubber
|
Product Weight
0.36 lbs
|
