This carbon steel female half quick disconnect coupling from Danfoss / Eaton's Hansen FD56 Series is designed for hydraulic and fluid transfer applications, including hydraulic tool (HTMA) interchange.
The DANFOSS / EATON CPLING 5600 SERIES FEMALE STEEL features a ball lock internal connection and FKM seals, offering a 2-way valve type and a flow rate of 28 gallons per minute. This coupling has a 0.75-inch NPT end.
It is certified to ISO 7241-1 Series A standards and operates effectively in temperatures as low as -15 degrees.
SKU: FD56-1225-12-12
Supplier Part Number (MPN): FD56-1225-12-12
|
Alternate Part Numbers
MINO-00402X03195
|
Application
Hydraulic tool (HTMA interchange), Hydraulic and fluid transfer
|
Certifications
ISO 7241-1 Series A
|
Brand
Danfoss Power Solutions (II LLC Aeroquip)
|
Brand
Aeroquip
|
Pack Size
1.00
|
UOM
EA
|
End Gender 1
13553
|
End Size 1
0.75
|
End Type 1
NPT
|
Features
Quick connect and disconnect|No need for special tools|Exceeds ISO 16028 operating pressures
|
Flow Rate1
28 gallons per minute
|
ICC
Quick Disconnect Couplings
|
Internal Connection Type
Ball Lock
|
Item Type
Female Half
|
Language
English
|
Minimum Working Temperature
-15
|
Net Pack Quantity Units
EA
|
Product Material
Carbon Steel
|
Product Width
1.81
|
Seal Material
FKM
|
Sub Brand
Hansen
|
Supplier Part Number
FD56-1225-12-12
|
Valve Type
2 way
|
Product Weight
0.94 lbs
|
