Designed for hydraulic and fluid transfer applications including mining equipment, the Danfoss / Eaton Couplings - Code Cp is part of the Hansen FD86 Series and built to handle demanding quick disconnect requirements. Constructed from carbon steel with Buna-N seals, these couplings are rated for a minimum working temperature of -40°F and support flow rates up to 50 gallons per minute.
Connection is thread-to-connect, requiring no special tools for engagement or release. The FD86 Series exceeds ISO 16028 operating pressure standards, making it well suited for high-demand hydraulic circuits. The Aeroquip/Hansen sub-brand backing reflects consistent industrial-grade quality across the product line.
SKU: FD86-1016-16
Supplier Part Number (MPN): FD86-1016-16
|
Alternate Part Numbers
MINO-00402X03252
|
Application
Hydraulic and fluid transfer, Mining equipment
|
Brand
Danfoss Power Solutions (II LLC Aeroquip)
|
Brand
Aeroquip
|
Pack Size
1.00
|
UOM
EA
|
Features
Quick connect and disconnect|No need for special tools|Exceeds ISO 16028 operating pressures
|
Flow Rate1
50 gallons per minute
|
ICC
Quick Disconnect Couplings
|
Internal Connection Type
Thread to Connect
|
Item Type
Component
|
Language
English
|
Minimum Working Temperature
-40
|
Net Pack Quantity Units
EA
|
NMFC
50
|
Product Material
Carbon Steel
|
Product Width
2.50
|
Seal Material
Buna-N
|
Sub Brand
Hansen
|
Supplier Part Number
FD86-1016-16
|
Product Weight
0.71 lbs
|
