Danfoss / Eaton;Danfoss / Eaton;Hose SiliconeSaeJ20 Red;FF90829-36;Hose SiliconeSaeJ20 Red;Working Pressure 40 PSI

Description & Features

Eaton Industrial Hose offers this Danfoss / Eaton Hose Silicone SaeJ20 Red for high-temperature vibration isolation in air aspiration units. Constructed with a red silicone cover and tube, and reinforced with aramid, it features a highly abrasion-resistant cover for premium durability and proven reliability.

This conductive hose is built with a 4-ply construction and certified to SAE J20 standards. It has a -36 dash size, a 6.5" minimum bend radius and is designed to withstand a working pressure of 40 PSI. The minimum working temperature is -54 degrees.

SKU: FF90829-36

Supplier Part Number (MPN): FF90829-36

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00015X12168	Application High temperature vibration isolation for air aspiration units.	Certifications SAE J20	Color Red	Conductivity 30	Construction 4 Ply	Cover Material Silicone	Dash Size -36	Brand Danfoss (Aeroquip Inc-Industrial Hose)	Brand Aeroquip	Pack Size 1.00	UOM EA	Features Highly abrasion resistant cover\|Small number of hoses for many fuel options\|Proven reliability with high temperature resistance	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 6.50	Minimum Bend Radius 6.5	Minimum Working Temperature -54	Net Pack Quantity Units EA	NMFC 70	Product Width 2.64	Reinforcement Material Aramid	Sub Brand None	Supplier Part Number FF90829-36	Tube Material Silicone	Product Weight 0.14 lbs

Product Questions & Answers (3)

Question by: Johnny B on May 1, 2025, 4:04 PM

Hey, will this hose work okay if I need to bend it a good bit?

Answer by: Customer Support on May 3, 2025, 8:27 AM

Minimum bend radius on this hose is 6.5 inches, so keep that in mind when routing it.

Question by: Brent W on Sep 21, 2025, 4:46 PM

got a tight spot on my air intake run. how sharp can i bend this -36 hose without kinkin it

Answer by: Customer Support on Sep 23, 2025, 6:20 AM

For bend limits, the minimum bend radius on this hose is 6.5 inches. Staying at or above that radius helps keep it from kinking and protects the 4 ply aramid reinforcement.

Question by: Earl W on Sep 23, 2025, 9:35 AM

what's the lowest temp this hose can handle? running some equipment through some pretty brutal winters and need to know it won't get stiff and crack on me

Answer by: Customer Support on Sep 24, 2025, 6:55 PM

Rated down to -54 degrees, so cold weather operation shouldn't be an issue for most winter conditions you'd run into. The silicone construction holds up well at low temps without getting brittle, which is exactly what you want on equipment that sits outside overnight or starts up cold.
