Description & Features

Designed for heavy-duty coolant service, this Eaton Industrial Hose silicone hose meets SAE J20 certification and is well-suited for applications where vibration isolation is a priority. The blue silicone cover offers premium abrasion resistance, while the four-ply polyester-reinforced construction supports a working pressure of 40 PSI. Both the tube and cover are silicone, providing reliable performance across a wide temperature range down to -54°C.

The Danfoss / Eaton FF90830-56 carries a minimum bend radius of 6.5 inches and features conductive construction, making it appropriate for fuel and coolant routing in demanding engine environments. Lay line identification is applied via ink jet. The -56 dash size suits larger-diameter coolant circuit requirements common in heavy equipment and industrial engine applications.

SKU: FF90830-56

Supplier Part Number (MPN): FF90830-56

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00015X12188	Application Heavy duty coolant applications. Applications requiring vibration isolation.	Certifications SAE J20	Color Blue	Conductivity 30	Construction 4 Ply	Cover Material Silicone	Dash Size -56	Brand Danfoss (Aeroquip Inc-Industrial Hose)	Brand Aeroquip	Pack Size 1.00	UOM EA	Features Highly abrasion resistant cover\|Small number of hoses for many fuel options\|Proven reliability with high temperature resistance	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 6.50	Minimum Bend Radius 6.5	Minimum Working Temperature -54	Net Pack Quantity Units EA	NMFC 70	Product Width 3.94	Reinforcement Material Polyester	Sub Brand None	Supplier Part Number FF90830-56	Tube Material Silicone	Product Weight 0.14 lbs

Product Questions & Answers (2)

Question by: Tammy M on May 9, 2025, 9:21 PM

working on a big industrial cooling system and need something that can handle vibration real good without cracking up on me, this hose rated for that kind of use?

Answer by: Customer Support on May 11, 2025, 9:19 AM

Vibration isolation is actually one of the main applications this hose was built for. The silicone construction absorbs movement and flex better than rubber alternatives in most heavy-duty cooling setups, so it holds up well in environments where the engine or machinery is constantly shaking the lines around. Rated to 40 PSI working pressure and built with four-ply polyester reinforcement, it gives you solid durability without going stiff on you over time.

Question by: Todd Y on Jun 1, 2025, 10:07 AM

got a tight spot on a coolant run, how sharp can that FF90830-56 hose bend without kinking

Answer by: Customer Support on Jun 3, 2025, 6:18 AM

For routing, the minimum bend radius on the FF90830-56 is 6.5 inches, so you want to keep your bends at or above that to avoid stressing the hose.
