Aeroquip Reusable ORS FIT

Description & Features

A 90-degree long elbow configuration makes this carbon steel fitting well suited for hydraulic hose assemblies where routing space is limited or directional changes are required. The Aeroquip Reusable ORS Fit belongs to the Aeroquip FJ9709 Series and features an ORS swivel female end paired with a line/hose/tube end, with a hose dash size of -8 and a hex size of 0.94 inches.

Constructed from carbon steel for durability in demanding hydraulic environments, this reusable fitting is designed to reduce assembly time and support efficient production workflows. The reusable design allows the fitting to be removed and reattached without replacing the component, which can lower long-term maintenance costs on equipment where hose replacement is routine.

SKU: FJ9709-0808S

Supplier Part Number (MPN): FJ9709-0808S

Specifications

Brand Aeroquip® by Danfoss	a Dimensions 2.88 in	Compatible Hose ID 1/2 in	Connection Size 1 1/2 in	Connection Size 2 1/2 in	Connection Type Female ORFS Swivel, Hose	Connection Type 1 Hose	Connection Type 2 Female ORFS Swivel	Construction Style Reusable	Cut-Off Factor 1.73 in	Dimensions 0.36 in ID	Drop Dimensions 3 in	End Connection Torque 35 to 46 lb-ft	End Gender 1 Female	End Size 1 13/16 in	Finish Dura-Kote™	Fitting Type 90 deg Elbow	For Use With 1503, 2580, 2651, FC234, FC300, FC321, FC350, FC355 and FC802 Series Hoses	Hex Size 0.94 in	Hose Dash Size 08	Inside Diameter 0.36 in	Material Steel	Material Construction Carbon Steel	Series FJ9709 Series	Thread Sealant Without Thread Sealant	Thread Size 13/16-16	Thread Type UN

Product Questions & Answers (1)

Question by: Harold W on Jul 23, 2025, 9:43 AM

If I take this thing apart to clean it, will I need to replace anything when I put it back together?

Answer by: Customer Support on Jul 25, 2025, 6:04 AM

Because this is a reusable fitting, you shouldn't need to replace any parts when you reassemble it after cleaning. Just make sure everything is properly tightened.
