Danfoss / Eaton Swivel Joint

Description & Features

Designed for rotational flexibility in hydraulic lines, this 1-inch steel swivel joint is part of the Danfoss / Eaton FS6500 Series and features female NPTF connections on both ends. The all-steel construction supports reliable service in demanding industrial environments, with a rated minimum working temperature of -20°F. The 1.625-inch hex size on the secondary end facilitates straightforward installation with standard tooling.

The Danfoss / Eaton Swivel Joint is well suited for hydraulic circuits where relative movement between connected components requires a rotating union to prevent hose stress or line fatigue. Both ends use 1-inch female NPTF threading, providing a pressure-tight mechanical seal compatible with standard hydraulic fittings in that port size.

SKU: FS65008-1616-06

Supplier Part Number (MPN): FS65008-1616-06

Specifications

Brand
Aeroquip® by Danfoss
Connection Size 1
1 in
Connection Size 2
1 in
Connection Type
FNPT
Connection Type 1
Female NPTF
Connection Type 2
Female NPTF
Dimensions
3.84 in L x 3.7 in H
Finish
Zinc-Plated
Fitting Type
Swivel Joint
Fluid
Aromatic solvents, Chemicals, Gasoline
Hex Size
1-5/8 x 1-11/16 in
Material
Steel
Material Construction
Carbon Steel
Maximum Operating Pressure
3000 psi
nmfc
50
Operating Temperature
300 deg F
Segment Code
C
Series
FS65008 Series
Thread Sealant
Without Thread Sealant
Thread Size
1-11-1/2

Similar Products

Model Number Connection Size 1 Connection Size 2 Connection Type Dimensions Price Action
FS65 Series Standard Duty Balanced Pressure Swivel Joint, 1-11-1/2 Female Pipe Casing Thread To 1-11-1/2 Female Pipe Sleeve Thread

FS65008-1616-01 FS65 Series Swivel Joint

1 in

1 in

FNPT

3.84 in L x 3.7 in H

FS65 Series Standard Duty Balanced Pressure Swivel Joint, 1/2-14 Female Pipe Casing Thread To 1/2-14 Female Pipe Sleeve Thread

FS65008-0808-01 FS65 Series Swivel Joint

1/2 in

1/2 in

FNPT, MNPT

3.14 in L x 2.65 in H

FS65 Series Standard Duty Balanced Pressure Swivel Joint, 3/8-18 Female Pipe Casing Thread To 3/8-18 Female Pipe Sleeve Thread

FS65008-0606-01 FS65 Series Swivel Joint

3/8 in

3/8 in

FNPT

2.49 in L x 2.28 in H

DANFOSS / EATON SWIVEL JOINT

FS65002-1212-01

3/4 in

3/4 in

FNPSM Swivel, Male SAE ORB

3.28 in L x 3.09 in H

DANFOSS / EATON SWIVEL JOINT 90 DEG MJIC

FS65003-0808-01

1/2 in

1/2 in

Male JIC, MNPT

2.88 in L x 2.66 in H

Danfoss / Eaton Swivel Joint

FS65003-1212-01

3/4 in

3/4 in

Male JIC, MNPT

3.21 in L x 3.31 in H

DANFOSS / EATON SWIVEL JOINT 90 DEG MJIC

FS65004-1010-01

5/8 in

5/8 in

Male JIC

2.87 in L x 2.77 in H

Danfoss / Eaton Swivel Joint Male JIC X Male JIC

FS65004-1212-01

3/4 in

3/4 in

Male JIC

3.31 in L x 3.31 in H

Danfoss / Eaton Swivel Joint 90 Deg FP X

FS65008-0404-01

1/4 in

1/4 in

FNPT

2.49 in L x 2.27 in H

Danfoss / Eaton Swivel Joint 90 Deg FP X

FS65008-0808-06

1/2 in

1/2 in

FNPT

3.14 in L x 2.65 in H

DANFOSS / EATON #12 FP(RIGID) X #12 FP HYD. SWIVEL

FS65008-1212-01

3/4 in

3/4 in

FNPT

3.21 in L x 3.25 in H

DANFOSS / EATON SWIVEL

FS65009-0808-01

1/2 in

1/2 in

Male JIC, Male SAE ORB

2.61 in L x 2.46 in H

FS65 Series Standard Duty Balanced Pressure Swivel Joint, 1-1/16-12 Male JIC 37 deg Flare Casing Thread To 1-1/16-12 Male SAE O-Ring Boss (Straight Thread O-Ring) Sleeve Thread

FS65009-1212-01 FS65 Series Swivel Joint

3/4 in

3/4 in

Male JIC, Male SAE ORB

3.31 in L x 3.31 in H

Product Questions & Answers (1)

Question by: Warren S on Mar 2, 2026, 7:44 PM
Reckon this would hold up okay in a hydraulic setup that's runnin' pretty much non-stop?
Answer by: Customer Support on Mar 4, 2026, 6:12 AM
All-steel construction is what makes this Danfoss/Eaton swivel joint reliable for demanding industrial environments, even with pretty constant use.
