AQP REFRIG HOSE

Description & Features

The AQP Refrigeration Hose from Danfoss Power Solutions Aeroquip is engineered to meet the rigorous demands of air conditioning and refrigeration in construction agriculture and truck applications. Featuring a durable 1 Ply Braid construction with a black EPDM cover it ensures reliable performance even in harsh environments.

Certified to exceed SAE J2064 standards this hose boasts compatibility with multiple refrigerants making it a versatile option for various systems. Designed to withstand a minimum bend radius of 2 inches and a minimum working temperature of -40 degrees it delivers maximum uptime and reliability.

Completed with ink jet lay line style and qualified for EZ Clip or factory crimp hose fittings it provides a secure and efficient connection for optimal use. The polyamide tube material and standard abrasion resistance further enhance its durability and effectiveness.

MPN: GH001-6RL

Supplier Part Number: GH001-6RL

Specifications

Abrasion Resistance Premium	Color Black	Conditional Temp Range -50 to 302 deg F Oil	Construction 1-Textile Braided	Cover Material EPDM	Dash Size 06	Effusion Rate <1 kg/sq-m/yr at 80 deg C R1234yf Effusion, <1.5 kg/sq-m/yr at 80 deg C R134a Effusion	For Use With FJ Series Hose Fittings	Hose Color Black	Hose Type Conductive	Impulse Cycle 150000	Impulse Cycle Life 150000	Inside Diameter 0.33 in	Lay Line Style Inkjet	Length 1 ft	Nominal Size #06	Package Form Reel	Qualified Hose Fittings FJ	Reinforcement 1-Textile Braided Fabric	Reinforcement Material Fabric	Resistance Abrasion	Resistance Properties Abrasion	Series GH001 Series	Tube Material Polyamide

Product Questions & Answers (1)

Question by: Joyce M on Jun 2, 2025, 9:22 AM

Does this hose work with R1234yf or is it only rated for the older R134a refrigerant?

Answer by: Customer Support on Jun 4, 2025, 6:24 AM

Both refrigerants are covered. The effusion rate for R1234yf runs under 1 kg per square meter per year at 80 degrees C, and R134a comes in under 1.5 kg per square meter per year at the same temperature. It meets SAE J2064 Type E, Class 2 certification, so it holds up to current standards for either refrigerant in A/C and refrigeration work across construction, agriculture, and truck applications.
