Aeroquip 100FT CL Hose

Description & Features

Rated for hydraulic system service with petroleum-based, fire-resistant, and water-base fluids, as well as fuel and lubricating systems, this -8 dash size hose is built for demanding industrial applications. The Aeroquip 100FT CL Hose features a dual-layer, high-tensile steel cord braid reinforcement with an elastomer tube and elastomer cover, delivering robust performance across a wide temperature range starting at -40°F minimum. Construction meets SAE 100R2AT Type S, EN853 2SN, and ISO 1436-1 Type 2SN standards, with additional compliance to DNV, MSHA, and USCG requirements.

With a minimum bend radius of 7.01 inches and a rated impulse cycle life of 400,000 cycles, this hose is suited for high-pressure hydraulic circuits where longevity and reliability matter. Compatible with crimp, 1A, and skive nipple fittings, it carries a conductive designation and is finished in blue with an ink transfer lay line. The 0.89-inch product width and 100-foot continuous length make it practical for assembly shops and field fabrication alike.

SKU: GH195-8-12000

Supplier Part Number (MPN): GH195-8-12000

Specifications

Abrasion Resistance 29	Alternate Part Numbers Alternate Part Number MINO-00015X13603	Application Hydraulic system service with petroleum, fireresistant and waterbase fluids, fuel and lubricating systems.	Certifications SAE 100R2AT Type S\|EN853 2SN\|ISO 1436-1 Type 2SN	Class WEB-ITEM	Color Blue	Compliances DNV\|MSHA Approved\|USCG	Conductivity 30	Construction 2-ply braid	Cover Material Elastomer	Dash Size -8	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	Features Maximum durability under harsh operating conditions\|Robust construction able to withstand highest pressures\|System engineered to extend hose assembly life	ICC Hoses and Flexible Tubes	Impulse Cycle Life 400000 cycle	Language English	Lay Line Style Ink Transfer	Minimum Bend Radius 7.01	Minimum Bend Radius 7.01	Minimum Working Temperature -40	Product Width 0.89	Qualified Hose Fittings Crimp, 1A, Skive Nipple	Reinforcement Material High-tensile steel cords	Supplier Part Number GH195-8-12000	Tube Material Elastomer	Product Weight 0.99 lbs

Product Questions & Answers (1)

Question by: Dean P on May 3, 2025, 9:19 AM

Reckon this hose'll hold up alright in a hydraulic setup runnin' pretty hot?

Answer by: Customer Support on May 4, 2025, 9:22 AM

This Aeroquip hose is designed to handle a wide temperature range, with a minimum working temperature of -40°F, so it should perform well in demanding hydraulic systems.
