Boston Bosflex A/W hose

Description & Features

The black Boston Bosflex A/W hose is designed for general air and water applications. Featuring a pin-pricked EPDM cover and EPDM tube, this hose offers standard abrasion resistance and reliable performance.

Constructed with a 4-spiral polyester reinforcement, the Boston Bosflex A/W hose maintains a minimum bend radius of 5.75 inches and is suitable for use with Z, 1A, Barbed inserts, and Quick Disconnect qualified hose fittings. It performs reliably in temperatures as low as -40 degrees.

SKU: H010512BK-600R

Supplier Part Number (MPN): H010512BK-600R

Specifications

Abrasion Resistance 29	Alternate Part Numbers Alternate Part Number MINO-00925F22379	Application General air and water.	Color Black	Conductivity 30	Construction 4 Spiral	Cover Material EPDM	Cover Style Pin-Pricked	Dash Size -12	Brand Danfoss (IGS)	Brand Danfoss Power Solutions	Pack Size 1.00	UOM FT	Features A solution for every hose need\|Industry leader since 1870\|Designed for safety and reliability	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 5.75	Minimum Bend Radius 5.75	Minimum Working Temperature -40	NMFC 70	Product Width 1.18	Qualified Hose Fittings Z, 1A, Barbed inserts, Quick Disconnect	Reinforcement Material Polyester	Sub Brand None	Supplier Part Number H010512BK-600R	Tube Material EPDM	Product Weight 0.14 lbs

Product Questions & Answers (1)

Question by: Connie B on Oct 4, 2025, 7:50 AM

How tight of a bend can I get away with on this hose? I'm working in a pretty compact space.

Answer by: Customer Support on Oct 5, 2025, 9:53 PM

The minimum bend radius for the Boston Bosflex A/W hose is 5.75 inches. Trying to bend it tighter than that could damage the hose.
