Chemcat Petrochemical Co PRP 2 | 3 | 150

Description & Features

Designed for chemical transfer in petrochemical and marine environments, the Chemcat Petrochemical Co PRP 2 | 3 | 150 is a purple-jacketed industrial hose built with a UHMW-PE FDA-approved tube and an EPDM corrugated cover. The two-ply braid construction incorporates fiber and helical wire reinforcement, providing structural integrity and flexibility with a minimum bend radius of 6.5 inches.

Rated for service down to -40°F, this hose is well-suited for demanding chemical handling applications. Compatible fitting types include cam and groove, combination nipple, and male NPT connections. The hose carries SAE J1942/1 and ABS certifications, with USCG and NMMA compliance, making it appropriate for commercial marine as well as industrial chemical transfer use.

SKU: H059948-150

Supplier Part Number (MPN): H059948-150

Specifications

Brand
Aeroquip® by Danfoss
Abrasion Resistance
Standard
Conductivity
Conductive
Cover Material
EPDM
Cover Style
Corrugated
Dash Size
48
For Use With
U Series Hose Fittings
Hose Color
Purple
Hose Type
Chemical
Inside Diameter
3 in
Lay Line Style
Ink Transfer
nmfc
70
Nominal Size
#03
Qualified Hose Fittings
Cam and Groove, Combination Nipple, Male NPT
Reinforcement
2-Ply Braided Fabric
Reinforcement Material
Fiber and Helical Wire
Resistance Properties
Abrasion
Series
H0599 Series
Tube Material
UHMW

Product Questions & Answers (1)

Question by: Todd S on Oct 13, 2025, 2:57 PM
What fittings work with this hose?
Answer by: Customer Support on Oct 15, 2025, 6:44 AM
Cam and groove, combination nipple, and male NPT connections all work with this hose.
