Danfoss / Eaton Polyforce II 3/8ID YELLOW 250PSI

Description & Features

Rated for 250 PSI working pressure, this 3/8" ID general-purpose hose is built for low-pressure air and water service across a wide range of industrial environments. The Danfoss / Eaton Polyforce II 3/8ID Yellow 250PSI features a polyvinyl chloride tube with a single-ply textile braid reinforcement and a pin-pricked PVC cover that resists abrasion and supports flexibility down to -10°F minimum working temperature.

The yellow cover aids visibility in busy shop and plant environments. With a conductive construction and SAE J517 certification, this hose meets recognized industry standards for safety and reliability. Compatible fittings include Type E, Z, 265 P, 1A, barbed inserts, quick-acting or long shank, and quick disconnect styles, giving installers broad flexibility in termination options. The 1" minimum bend radius keeps routing manageable in tight spaces, and the -6 dash size aligns with standard hydraulic and pneumatic sizing conventions.

SKU: H27506YW-250

Supplier Part Number (MPN): H27506YW-250

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00115X00577	Application General purpose, low pressure, air and water.	Certifications SAE J517	Class WEB-ITEM	Color Yellow	Conductivity 30	Construction 1 Ply Braid	Cover Material PVC	Cover Style Pin-Pricked	Dash Size -6	Brand Danfoss (IGS)	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features A solution for every hose need\|Industry leader since 1870\|Designed for safety and reliability	ICC Hoses and Flexible Tubes	Language English	Minimum Bend Radius 1	Minimum Bend Radius 1	Minimum Working Temperature -10	Product Width 0.63	Qualified Hose Fittings E, Z, 265 P, 1A, Barbed inserts, Quick acting or long shank, Quick disconnect	Reinforcement Material Textile	Supplier Part Number H27506YW-250	Tube Material Polyvinyl Chloride (PVC)	Product Weight 0.99 lbs

Product Questions & Answers (1)

Question by: Daryl L on Apr 22, 2025, 9:29 PM

What kinda fittings will work with this hose?

Answer by: Customer Support on Apr 24, 2025, 1:13 PM

Qualified fittings include Type E, Z, 265 P, 1A, barbed inserts, quick acting or long shank, and quick disconnect styles. So, you've got a good range of options there.
