Danfoss / Eaton Black LINE LPG 1IN

Description & Features

Designed for natural gas service, this 1-inch conductive hose features a synthetic rubber tube and cover with a single-ply textile braid reinforcement. The pin-pricked cover style supports pressure verification and helps prevent blister formation. With a minimum bend radius of 12 inches and a working temperature range starting at -40°F, it suits demanding industrial gas handling environments where flexibility and low-temperature performance are both required.

The Danfoss / Eaton Black LINE LPG 1IN carries RMA Class A certification and is compatible with Z, 1A, and 1G fittings, as well as swage or crimp male couplings, giving installers a range of termination options. At a dash size of -16 and a product width of 1.53 inches, the hose is straightforward to specify into existing gas distribution assemblies.

SKU: H90016-100

Supplier Part Number (MPN): H90016-100

Specifications

Abrasion Resistance 29	Alternate Part Numbers Alternate Part Number MINO-00115X00668	Application Natural gas	Certifications RMA Class A	Color Black	Conductivity 30	Construction 1 Ply Braid	Cover Material Synthetic Rubber	Cover Style Pin-Pricked	Dash Size -16	Brand Danfoss (IGS)	Brand Danfoss Power Solutions	Pack Size 12.00	UOM FT	Features A solution for every hose need\|Industry leader since 1870\|Designed for safety and reliability	ICC Hoses and Flexible Tubes	Language English	Minimum Bend Radius 12	Minimum Bend Radius 12	Minimum Working Temperature -40	Product Width 1.53	Qualified Hose Fittings Z, 1A, 1G fitting, Swage or Crimp male couplings	Reinforcement Material Textile	Supplier Part Number H90016-100	Tube Material Synthetic Rubber	Product Weight 0.39 lbs

Product Questions & Answers (1)

Question by: Daryl R on Oct 20, 2025, 7:11 AM

Will this hose hold up if it's constantly exposed to the elements?

Answer by: Customer Support on Oct 22, 2025, 6:32 AM

Designed with a synthetic rubber cover, this hose offers standard abrasion resistance, which should help it withstand typical outdoor conditions.
