HE2000 Series BARNES HE2000 REServoIR 1.9L Kit

Description & Features

The Concentric HE2000 Series Power Units include versatile reservoirs, offering both translucent plastic and steel options with capacities ranging from 0.13 to 4 gallons. These units incorporate highly efficient, pressure-balanced W Series and fixed clearance GC Series gear pumps, known for their low noise levels and reliability. Designed for various industrial applications, the series supports both DC and AC motor operations, accommodating 12 V, 24 V, 115V, 230V, and 460V motors.

Adapters: All units come with standardized adapter sizes.

Flow Controls: Optional built-in pressure-compensated flow regulators ensure consistent lowering speeds from 1 to 4 gpm, independent of load.

Motors: Available in DC and AC options, optimized for efficient, long service life and minimal power consumption.

Recommended Filtration: ISO 4406 cleanliness level 18/14 or better is advised for optimal performance.

Recommended Fluids: Suitable for most premium petroleum-based fluids with an optimal viscosity range of 80-288 SSU.

Relief Valves: Cartridge-style valves offer dependable, long-lasting performance.

Start Switches: Compatible with 12 VDC, 24 VDC, 115V to 460V AC, available in various configurations and duty ratings.

Temperature Range: Operates efficiently within -13deg;F to 175deg;F.

Valves: Screw-in cartridge with options up to 4 individual functions, including high-performance cartridge check valve standards.

Supplier Part Number: 1300899

MPN: C1MN23

Specifications

Brand concentric	For Use With concentric HE2000 Hydraulic Power Packs	Key VII	Material Steel	Specifications 2 qt Nominal Capacity

Similar Products

Model Number	For Use With	Price	Action
1303549 HE2000 Series AC/DC HPU Part	concentric HE2000 Hydraulic Power Packs
1300943 HE2000 Series AC/DC HPU Part	concentric HE2000 Hydraulic Power Packs and W Series Hydraulic Pumps
1303649 HE2000 Series AC/DC HPU Part	concentric HE2000 Hydraulic Power Packs
1303570 HE2000 Series AC/DC HPU Part	concentric HE2000 Hydraulic Power Packs
1303650 HE2000 Series AC/DC HPU Part	concentric HE2000 Hydraulic Power Packs
1303661 HE2000 Series AC/DC HPU Part	concentric HE2000 Hydraulic Power Packs
2330004 HE2000 Series AC/DC HPU Part	concentric HE2000 Hydraulic Power Packs
1303534 HE2000 Series AC/DC HPU Part	concentric HE2000 Hydraulic Power Packs
1300878 HE2000 Series AC/DC HPU Part	concentric HE2000 Hydraulic Power Packs, GC and W Series Hydraulic Pumps
1300908 HE2000 Series AC/DC HPU Part	concentric HE2000 Hydraulic Power Packs

Product Questions & Answers (2)

Question by: Tommy W on Sep 18, 2025, 9:51 PM

got a piece of equipment sitting outside in the winter. how cold can it get before the unit stops working and what kinda fluid goes in here

Answer by: Customer Support on Sep 20, 2025, 6:07 AM

Petroleum based fluids are going to be your best bet for the reservoir. The system handles temperatures down to -13 degrees Fahrenheit. For winter use you just want to make sure the cold start viscosity does not exceed 9000 SSU while the normal operating range sits between 80 and 288 SSU.

Question by: Ronnie A on May 10, 2025, 6:55 PM

got an HE2000 power unit with a cracked tank. is this 1.9L reservoir kit meant as a replacement part or is it only for new builds?

Answer by: Customer Support on May 12, 2025, 9:58 AM

Built as a reservoir kit for the HE2000 Series, it can be used either way. These kits are called out for repairing or modifying existing HE2000 Series power units, and they can also be used when you are putting together a custom HE2000 Series unit.
