Heavy Duty Hydrostatic Motor, 4.60 cu in/rev, SAE C 4-Bolt Mounting Flange, 14T SAE C Splined Shaft, 1 Inch Code 62 Ports, PSI High Pressure Relief

This Danfoss / Eaton Series 1 Heavy Duty Fixed Motor has a compact design offering dynamic machine control and being Pro-FX ready. With a displacement of 4.6 cu in/rev the motor features a 14T SAE C splined shaft and SAE C 4-bolt mounting flange ensuring easy installation and robust connectivity.

Engineered for high performance it supports a peak pressure of 6000 PSI and a speed rating of 4160 RPM. The high strength cast iron housings enhance noise damping and structural integrity while the advanced cylinder barrel design allows for high-speed and high-pressure endurance.

The bi-metal bearing plate with steel for high speed and bronze for bearing properties contributes to a 10 000-hour B10 bearing design life. Piston design ensures low leakage due to extended engagement with the cylinder bore.

Additional features include 1 Inch Code 62 ports and compatibility with fluid viscosities ranging from 80-180 SSU. A recommended filtration level of ISO 4406 Cleanliness Level 18/13 or cleaner is suggested.

MPN: C1HJ42

Supplier Part Number: 4633-091
