BRAKEQUIP FITTING - MALE SWIVEL NUT 1/2X20NF (90)

Ask A Question

Description & Features

Designed for brake line and hydraulic tubing connections, the Brakequip Fitting - Male Swivel Nut 1/2x20NF (90) provides a reliable 90-degree angled connection point suited to tight-clearance routing in automotive and light industrial brake systems. The male swivel nut configuration allows the fitting to rotate during installation, helping achieve proper alignment without twisting the line.

Threaded to a 1/2-20 NF (National Fine) specification, this fitting is compatible with standard brake line tubing and fittings using that thread designation. The 90-degree angle makes it particularly useful where straight fittings would interfere with surrounding components or require sharp bends in the connected line.

SKU: HF28

Supplier Part Number (MPN): HF28

Alternate Part Numbers: C1MA19

Specifications

Brand
BrakeQuip®
Connection Type
Male Flared Swivel x Tube
Hex Size
16 mm

Product Questions & Answers (1)

Question by: Hank B on Mar 16, 2026, 6:47 PM
Got a tight spot under the dash where a straight fitting just ain't gonna work, would this 90-degree swivel nut be the right call for rerouting a brake line in that kind of situation?
Answer by: Customer Support on Mar 17, 2026, 8:25 PM
That's exactly the kind of fix this fitting is built for. The 90-degree angle lets you make the connection without forcing a sharp bend in the line itself, which matters a lot when clearance is tight around other components. The swivel nut design also means you can rotate the fitting into position during installation without twisting the brake line along with it, so getting the angle right doesn't turn into a wrestling match.
