High Pressure Air Hose, Yellow, 3.15 Inch OD, 2.50 Inch ID, Up To 600.00 PSI

Ask A Question

Description & Features

This Eaton Industrial Hose is a high-pressure air hose designed for demanding industrial applications. The hose has a 2.50-inch inner diameter (ID) and a 3.15-inch outer diameter (OD).

The High Pressure Air Hose is constructed to withstand pressures up to 600.00 PSI. Its vibrant yellow color provides high visibility in busy industrial environments.

SKU: EHA500-40YW-100

Supplier Part Number (MPN): EHA500-40YW-100

Alternate Part Numbers: C1MK61

Specifications

Color
Yellow
Brand
Danfoss (IGS)
Brand
Danfoss Power Solutions
Pack Size
1.00
UOM
FT
Hose I.D.
2.50
Hose O.D.
3.15
Maximum Operating Pressure
600
Minimum Bend Radius
12.40
Minimum Bend Radius
12.4
Reel Qty (ft)
100
Supplier Part Number
EHA500-40YW-100
Alternate Part Numbers
Alternate Part Number C1MK61, Alternate Part Number MINO-00115X00216
Product Weight
0.64 lbs

Related Documents

Similar Products

Model Number Color Hose I.D. Hose O.D. Maximum Operating Pressure Burst Pressure Reel Qty (ft) Price Action
High Pressure Air Hose, Yellow, 2.60 Inch OD, 2.00 Inch ID, Up To 600.00 PSI

EHA500-32YW-100 High Pressure Air Hose

Yellow

2

2.6

600

100

High Pressure Air Hose, Yellow, 3.70 Inch OD, 3.00 Inch ID, Up To 600.00 PSI

EHA500-48YW-100 High Pressure Air Hose

Yellow

3

3.7

600

100

High Pressure Air Hose, Yellow, 4.80 Inch OD, 4.00 Inch ID, Up To 600.00 PSI

EHA500-64YW-100 High Pressure Air Hose

Yellow

4

4.8

600

100

High Pressure Air Hose, Yellow, 0.91 Inch OD, 0.50 Inch ID, Up To 600.00 PSI

EHA500-08YW-100 High Pressure Air Hose

Yellow

0.5

0.91

600

100

High Pressure Air Hose, Yellow, 1.16 Inch OD, 0.75 Inch ID, Up To 600.00 PSI

EHA500-12YW-100 High Pressure Air Hose

Yellow

0.75

1.16

600

100

High Pressure Air Hose, Yellow, 1.42 Inch OD, 1.00 Inch ID, Up To 600.00 PSI

EHA500-16YW-100 High Pressure Air Hose

Yellow

1

1.42

600

100

High Pressure Air Hose, Yellow, 1.69 Inch OD, 1.25 Inch ID, Up To 600.00 PSI

EHA500-20YW-100 High Pressure Air Hose

Yellow

1.25

1.69

600

100

High Pressure Air Hose, Yellow, 1.97 Inch OD, 1.50 Inch ID, Up To 600.00 PSI

EHA500-24YW-100 High Pressure Air Hose

Yellow

1.5

1.97

600

100

High Pressure Air Hose, Yellow, 3.15 Inch OD, 2.50 Inch ID, Up To 600.00 PSI

EHA500-40YW-100 High Pressure Air Hose

Yellow

2.5

3.15

600

100

Product Questions & Answers (2)

Question by: Kirk R on Aug 25, 2025, 12:58 PM
hose is 2.5 inch ID, that right? got a compressor line that size and need something rated well above what we're running
Answer by: Customer Support on Aug 26, 2025, 6:10 PM
Yeah, the ID on this one is 2.50 inches with a 3.15-inch OD. It's rated up to 600 PSI, so if your compressor line is running below that, you've got solid headroom to work with.
Question by: Rhonda D on Aug 26, 2025, 6:05 PM
need a big air hose and i dont wanna order the wrong size. what are the inside and outside measurements on this one?
Answer by: Customer Support on Aug 28, 2025, 7:24 AM
For sizing, the inner diameter is 2.50 inches and the outer diameter is 3.15 inches.
