HK Series Industrial Interchange Series B Dust Cap, -08 Coupling

Ask A Question

Description & Features

The HK Series Industrial Interchange Series B Dust Cap, -08 Coupling from Danfoss Power Solutions (II LLC Aeroquip) is designed for fluid transfer and hydraulic applications. This quality coupling is engineered to meet the rigorous dimensional standards of ISO 7241-1 Series B.

The design incorporates a self-sealing poppet valve, ensuring excellent sealing across high and low-pressure conditions. The standard seal material is Buna-N, with optional seals available in PTFE, Neoprene, FKM, EPDM, and Kalrezreg;. The temperature range varies by material, with Buna-N operational from -40deg;F to +250deg;F, Neoprene from -65deg;F to +212deg;F, EPDM up to +300deg;F, and FKM from -15deg;F to +400deg;F.

For enhanced reliability, PTFE backup rings are included in the female sockets. This dust cap is compatible with a -08 coupling size and is specified for female end gender with a 0.5-inch end size. No thread sealant is required, ensuring straightforward maintenance and use.

MPN: C1ML50

Supplier Part Number: PPDC4HK

Specifications

Coupling Size
-08
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
1.00
UOM
EA
End Gender 1
13553
End Size 1
0.50
Supplier Part Number
PPDC4HK
Thread Sealant
No
Alternate Part Numbers
Alternate Part Number C1ML50, Alternate Part Number MI-06231806, Alternate Part Number MINO-00402F46853, Alternate Part Number MINO-00402X04087
Product Weight
52.91 lbs

Related Documents

Similar Products

Model Number Coupling Size Price Action
HK Series Industrial Interchange Series B Dust Cap, -08 Coupling

PPDC4HK HK Series Coupling Dust Cap

-08

HK Series Industrial Interchange Series B Dust Cap, -04 Coupling

PPDC2HK HK Series Coupling Dust Cap

-04

HK Series Industrial Interchange Series B Dust Cap, -06 Coupling

PPDC3HK HK Series Coupling Dust Cap

-06

HK Series Industrial Interchange Series B Dust Cap, -12 Coupling

PPDC6HK HK Series Coupling Dust Cap

-12

HK Series Industrial Interchange Series B Dust Cap, -16 Coupling

PPDC8HK HK Series Coupling Dust Cap

-16

Product Questions & Answers (3)

Question by: Brett B on Jan 19, 2026, 10:41 AM
what seal material comes standard on these dust caps, and is there anything rated for higher temps if I need it?
Answer by: Customer Support on Jan 21, 2026, 9:45 AM
Buna-N is the standard seal, which handles a range of negative 40 up to 250 degrees Fahrenheit. If your application runs hotter than that, FKM seals are available and rated up to 400 degrees. EPDM is another option if you need something that can handle down to negative 65 on the cold end while still reaching 300 degrees on the high side. So there are a few paths depending on what you're dealing with.
Question by: Tony C on Oct 6, 2025, 12:03 PM
Will this dust cap fit my -08 Eaton Hansen coupling?
Answer by: Customer Support on Oct 7, 2025, 2:04 PM
Absolutely, this dust cap is specifically designed for a -08 coupling size in the Eaton HK Series.
Question by: Stan C on Jul 2, 2025, 6:52 AM
got a -08 quick disconnect on a hydraulic line. is this dust cap the right size for that?
Answer by: Customer Support on Jul 3, 2025, 10:25 AM
It is made for a -08 coupling size and the end is listed as female with a 0.5 inch end size.
