VFC Series Variable Flow Pressure Compensated Control Valve VFC40-K-A | TSK3018-7

Ask A Question

Description & Features

The WEBTEC VFC Series Variable Flow Pressure Compensated Control Valve is designed for efficient flow control in hydraulic systems, making it an essential component for industrial applications. With a maximum flow capacity of 40 L/min (10 US gpm) and a maximum pressure of 210 bar (3000 psi), this valve ensures reliable performance under demanding conditions. Its robust construction features an aluminum body and carbon steel internals, providing durability and longevity. The valve is compatible with mineral oils as per ISO 11158 standards, and it operates effectively across a fluid temperature range of -30 to 120 °C (-22 to 248 °F), ensuring versatility in various environments.

The VFC40-K-A model is equipped with 3/8” NPTF porting for easy integration into existing systems. Its seals are made from NBR and PTFE, offering excellent resistance to wear and chemical exposure. Weighing only 0.4 kg (0.9 lbs), this compact valve is designed for both reliability and ease of installation.

SKU: TSK3018-7

Supplier Part Number (MPN): VFC40-K-A

Specifications

Brand
Webtec
Pack Size
1.00
UOM
EA
Ambient Temperature
-30 to 50 °C, -22 to 122 °F
Body Materials
Aluminium
Compatible Fluid
Mineral oils to ISO 11158
Flow Range (US gpm)
0.5 - 10
Flow Range (L/min)
2 - 40
Fluid Temperature Range
-30 to 120 °C, -22 to 248 °F
Gross Weight
0.4 kg, 0.9 lbs
Internal Materials
Carbon Steel
Maximum Rated Flow
40 L/min, 10 US gpm
Max Rated Pressure
210 bar, 3000 psi
Net Weight
0.4 kg, 0.9 lbs
Porting
3/8” NPTF
Seals
NBR / PTFE
Product Weight
0.99 lbs

Related Documents

Product Questions & Answers (2)

Question by: Frank P on Nov 10, 2025, 6:42 PM
How can I make sure the VFC40-K-A valve fits my system's porting setup?
Answer by: Customer Support on Nov 12, 2025, 2:01 PM
This valve uses a 3/8” NPTF porting, which is pretty standard. Just check if your system's connections match this size to ensure compatibility.
Question by: Randy F on Apr 28, 2026, 4:41 PM
porting on this is 3/8 NPTF right? trying to match up to existing fittings on a test circuit and dont want to order the wrong thing
Answer by: Customer Support on Apr 30, 2026, 11:10 AM
3/8 NPTF is correct. That's a tapered thread, so it seals on the threads themselves rather than relying on a separate face seal or O-ring at the port. If your existing fittings are NPTF or NPT in that size, you're in good shape. Worth double-checking whether your current ports are tapered versus straight thread before you commit to the order.
