Hydraulic Vane Pump, Single pump, 8.39 cu in/rev, SAE C 2-bolt Mounting Flange, 1-1/4 Straight Keyed Shaft, SAE 4-Bolt Flange, Inlet 2", Outlet 1-1/4" Ports, CCW Rotation

Description & Features

The PERMCO Inc. Hydraulic Vane Pump is engineered for high-performance hydraulic systems. It offers a displacement of 8.39 cu in/rev and features a counterclockwise rotation ensuring efficient hydraulic operations.

This single pump model is equipped with an SAE C 2-bolt mounting flange and a 1-1/4 straight keyed shaft providing a secure and robust installation suitable for demanding industrial applications.

The unitrsquo;s design includes SAE 4-bolt flange ports with a 2" inlet and a 1-1/4" outlet facilitating seamless integration into various hydraulic systems.

PERMCO PUMP (7400 6131 002) is known for reliability in precision hydraulic applications with a design that meets stringent operational requirements.

MPN: PT7DSWB42XL01A1W1

Supplier Part Number: 7400-6131-0002

Specifications

Displacement 8.39	Displacement 8.39	Brand Permco Inc.	Brand Permco	Pack Size 1.00	UOM EA	Features Single pump	Mount SAE C 2-bolt	Mount SAE C 2-bolt	Ports SAE 4-Bolt Flange, Inlet 2", Outlet 1-1/4"	Ports SAE 4-Bolt Flange, Inlet 2", Outlet 1-1/4"	Rotation CCW	Shaft 1-1/4 Straight Keyed	Shaft 1-1/4 Straight Keyed	Supplier Part Number 7400-6131-0002	Alternate Part Numbers Alternate Part Number 7400-6131-0002, Alternate Part Number C1LC93, Alternate Part Number PT7DSWB42XL01A1W1, Alternate Part Number T7DSW-B42-XL01-A1-W1	Product Weight 72.00 lbs

Similar Products

Part Number	Displacement	Mount	Shaft	Ports	Rotation	Features	Price	Action
710-0091-032	14.65	2-Bolt SAE C	1-1/2 Straight Keyed	SAE 4-Bolt Flange, Inlet 3, Outlet 1-1/2	CW	Highest pressures, lowest noise\|Unique wafer plate design\|Single, double or triple pump
PT7DSWB42XL01A1W	8.39	SAE C 2-bolt	1-1/4 Straight Keyed	SAE 4-Bolt Flange, Inlet 2", Outlet 1-1/4"	CCW	Single pump

Product Questions & Answers (1)

Question by: Diane E on Jul 14, 2025, 5:47 PM

Reckon this'd be alright on a log splitter?

Answer by: Customer Support on Jul 15, 2025, 7:07 PM

This hydraulic vane pump is a single pump model with a displacement of 8.39 cu in/rev, designed for high-performance hydraulic systems where counterclockwise rotation is needed. Its SAE C 2-bolt mounting flange and 1-1/4 straight keyed shaft should allow for a robust installation in demanding industrial applications, like a log splitter if the specs line up.
