Weathergrip Z Series Hose End

Description & Features

Designed for general purpose low and medium pressure hydraulic systems, this carbon steel JIC 37° female swivel 90° elbow fitting connects a -4 dash size hose to a line or tube end with a reliable, articulating swivel joint. The Weathergrip Z Series Hose End is finished with Dura-Kote plating, providing strong corrosion resistance in demanding service environments. Where shock hazards are a concern, H277 or H435 hose is recommended in place of standard general purpose hose.

Engineered as a system-matched component, this fitting is designed to extend hose assembly service life and reduce downtime. It meets SAE J1176 certification requirements and carries a 0.5-inch end size with a drop dimension of 0.77 inches. Supplied by Danfoss Power Solutions under the Weatherhead brand, the Z Series line reflects a purpose-built approach to hose end fitting performance and longevity.

SKU: IG04Z-665

Supplier Part Number (MPN): 04Z-665

Specifications

Application General purpose low and medium pressure hydraulics. Use H277 or H435 where shock hazards exist	Certifications SAE J1176	Class WEB-ITEM	Drop Dimension 0.77	Brand Danfoss (IGS)	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	End Gender 1 13553	End Size 1 0.50	End Type 1 JIC 37	End Type 2 Line/Hose/Tube	Features Dura-Kote plating for superior corrosion resistance\|Innovative design to deliver performance and maximum uptime\|System engineered to extend hose assembly life	Hose Dash Size -4	ICC Hose Fittings	Item Type Fitting Assembly	Language English	Product Material Carbon Steel	Product Width 0.88	Supplier Part Number 04Z-665	Product Weight 0.13 lbs

Product Questions & Answers (1)

Question by: Eddie B on Nov 13, 2025, 2:32 PM

So this fitting here, it's for lower pressure stuff, right? Just want to make sure before I order.

Answer by: Customer Support on Nov 15, 2025, 6:00 AM

That's correct, this Weathergrip Z Series hose end is designed for general purpose low and medium pressure hydraulic systems.
