Weathergrip Z Series Hose End

Ask A Question

Description & Features

Designed for general purpose low and medium pressure hydraulic applications, the Weathergrip Z Series Hose End is a carbon steel fitting assembly suited for use where shock hazards are not a primary concern. It carries a -4 hose dash size and features an inverted female end connection, making it a practical choice for line, hose, and tube connections in a range of industrial hydraulic systems.

Built under the Weatherhead sub-brand by Eaton Aeroquip, this fitting meets SAE J1176 certification standards. Dura-Kote plating provides strong corrosion resistance, and the system-engineered design supports extended hose assembly service life. The fitting is manufactured with performance and uptime in mind, with a construction approach that integrates well into Weatherhead Z Series crimp assemblies. Fluid compatibility documentation is available from Eaton for reference during system specification.

SKU: IG04Z-755

Supplier Part Number (MPN): 04Z-755

Specifications

Application
General purpose low and medium pressure hydraulics. Use H277 or H435 where shock hazards exist
Certifications
SAE J1176
Brand
Danfoss (IGS)
Brand
Danfoss Power Solutions
Pack Size
1.00
UOM
EA
End Gender 1
13553
End Size 1
0.50
End Type 1
Inverted
End Type 2
Line/Hose/Tube
Features
Dura-Kote plating for superior corrosion resistance|Innovative design to deliver performance and maximum uptime|System engineered to extend hose assembly life
Hex Size 2
0.56
Hose Dash Size
-4
ICC
Hose Fittings
Item Type
Fitting Assembly
Language
English
Product Material
Carbon Steel
Product Width
0.88
Sub Brand
Weatherhead
Supplier Part Number
04Z-755
Product Weight
0.11 lbs

Related Documents

Product Questions & Answers (2)

Question by: Merle H on Feb 3, 2026, 7:49 PM
Got a -4 hose line I'm trying to fit out and need an inverted female end connection. This the right part for that setup?
Answer by: Customer Support on Feb 5, 2026, 6:31 AM
For a -4 hose dash size with an inverted female end connection, yes, that's exactly what this fitting is built for. It's a hose end assembly rated for general purpose low and medium pressure hydraulic systems, so as long as your application falls in that range and doesn't involve significant shock hazards, it should slot right into your line without issue.
Question by: Floyd A on Jul 18, 2025, 8:18 AM
Can this here Weathergrip Z series stand up to much corrosion, or will I be replacing it before long?
Answer by: Customer Support on Jul 20, 2025, 6:05 AM
Dura-Kote plating provides strong corrosion resistance, so it should hold up well under normal conditions.
