WEATHERHEAD H115 Hose

Description & Features

Designed for air and multipurpose industrial use, the Weatherhead H115 Hose is a Dash -6 hose built around a nitrile tube and a 2-ply polyester braid reinforcement, wrapped in a vinyl nitrile cover. The conductive construction and broad temperature range, down to -40°F, make it well suited for demanding shop and industrial environments where air lines and general-purpose fluid transfer are common.

The red vinyl nitrile cover provides standard abrasion resistance, with an ink jet lay line for straightforward identification. Compatible qualified fittings include Z and 430 U series, and the hose has a minimum bend radius of 3.5 inches. Eaton Weatherhead's H115 Series carries a heritage of industrial reliability dating back to 1870 under the Danfoss Power Solutions brand umbrella.

SKU: IGH11506-550R

Supplier Part Number (MPN): H11506-550R

Alternate Part Numbers: C1HB19

Specifications

Abrasion Resistance 29	Alternate Part Numbers Alternate Part Number C1HB19	Application Air and multi purpose.	Color Red	Conductivity 30	Construction 2-ply braid	Cover Material Vinyl Nitrile	Dash Size -6	Brand Danfoss (IGS)	Brand Danfoss Power Solutions	Pack Size 1.00	UOM FT	Features A solution for every hose need\|Industry leader since 1870\|Designed for safety and reliability	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 3.50	Minimum Bend Radius 3.5	Minimum Working Temperature -40	NMFC 70	Product Width 0.72	Qualified Hose Fittings Z, 430 U	Reinforcement Material Polyester	Supplier Part Number IGH11506-550R	Tube Material Nitrile	Product Weight 0.19 lbs

Product Questions & Answers (2)

Question by: Joyce S on Nov 20, 2025, 2:01 PM

hose says it's conductive, does that mean it's safe to run near electrical equipment or is that more about static discharge?

Answer by: Customer Support on Nov 22, 2025, 6:58 AM

Conductive construction in hoses like this is built to dissipate static electricity that can build up when fluids or air move through the line at speed. That matters most in environments where static buildup could cause ignition or interfere with sensitive equipment. It's not insulation from electrical sources, it's the opposite, actually. The conductivity gives static a path to ground rather than letting it accumulate inside the hose wall.

Question by: Dale G on Jul 7, 2025, 7:18 AM

got a dash 6 air line i need to swap out. is this H115 built for that kind of shop use?

Answer by: Customer Support on Jul 8, 2025, 9:11 PM

For shop air and general multipurpose industrial service, the H115 is a dash -6 hose with a nitrile tube, 2 ply polyester braid reinforcement, and a red vinyl nitrile cover with standard abrasion resistance.
