Weatherhead H470 Hydraulic Hose.

Description & Features

Engineered for heavy-duty hydraulic applications the Weatherhead H470 Hydraulic Hose ensures maximum durability and robustness. Designed by Danfoss this hose meets the stringent standards of EN856 Type R13 and SAE 100R13. Featuring a multi-spiral construction it provides exceptional strength and reliability making it ideal for use in hydraulic systems with petroleum and water-based fluids.

The premium nitrile cover and tube offer excellent resistance to abrasion while the wire reinforcement material enhances its high-pressure endurance. The hose boasts a minimum bend radius of 4.75 ensuring flexibility during installation.

Certified by MSHA ABS and USCG this hydraulic hose is built to withstand up to 1 000 000 impulse cycles extending the life of hose assemblies. The embossed lay line style adds an additional layer of quality and identification. Operating efficiently at temperatures as low as -40 it delivers consistent performance under harsh conditions.

Supplier Part Number: H47112

Specifications

Abrasion Resistance 28	Application Hydraulics system service wirh petroleum and water based fluids, for general use	Certifications EN856 Type R13\|SAE 100R13	Class WEB-ITEM	Color Black	Compliances MSHA Approved\|ABS Certified\|USCG	Construction Multi Spiral	Cover Material Nitrile	Dash Size -12	Brand Danfoss (IGS)	Brand Danfoss Power Solutions	Pack Size 1.00	UOM FT	Features Maximum durability under harsh operating conditions\|Robust construction able to withstand highest pressures\|System engineered to extend hose assembly life	ICC Hoses and Flexible Tubes	Impulse Cycle Life 1000000 cycle	Language English	Lay Line Style Embossed	Minimum Bend Radius 4.75	Minimum Bend Radius 4.75	Minimum Working Temperature -40	Product Width 1.26	Qualified Hose Fittings 6S	Reinforcement Material Wire	Supplier Part Number H47112	Tube Material Nitrile	Product Weight 43.00 lbs

Product Questions & Answers (1)

Question by: Melvin T on Jan 8, 2026, 6:46 AM

What kind of hydraulic fluids can I run through this hose, besides just the regular petroleum stuff?

Answer by: Customer Support on Jan 9, 2026, 7:52 AM

This hose is designed for use with both petroleum-based and water-based hydraulic fluids, making it pretty versatile for different hydraulic systems.
