Weatherhead H470 Hydraulic Hose.

Description & Features

Designed for high-pressure hydraulic service with petroleum and water-based fluids, the Weatherhead H470 Hydraulic Hose is built to handle demanding conditions across general industrial hydraulic applications. The -16 dash size hose features a multi-spiral wire reinforcement construction with a nitrile tube and nitrile cover, delivering reliable performance at a minimum bend radius of 6 inches and a rated impulse cycle life of one million cycles.

Certified to SAE 100R13 and EN856 Type R13 standards, this hose also carries MSHA, USCG, and ABS approvals, making it suitable for use in regulated environments. The black embossed lay line cover resists abrasion under harsh service conditions, and the hose is compatible with 6S qualified fittings. Operating temperature range starts at -40°F, supporting reliable function in cold-weather environments. The multi-spiral construction is engineered to extend assembly service life under sustained pressure cycling.

SKU: IGH47116

Supplier Part Number (MPN): H47116

Specifications

Abrasion Resistance 28	Application Hydraulics system service wirh petroleum and water based fluids, for general use	Certifications SAE 100R13\|EN856 Type R13	Class WEB-ITEM	Color Black	Compliances MSHA Approved\|USCG\|ABS Certified	Construction Multi Spiral	Cover Material Nitrile	Dash Size -16	Brand Danfoss (IGS)	Brand Danfoss Power Solutions	Pack Size 1.00	UOM FT	Features Maximum durability under harsh operating conditions\|Robust construction able to withstand highest pressures\|System engineered to extend hose assembly life	ICC Hoses and Flexible Tubes	Impulse Cycle Life 1000000 cycle	Language English	Lay Line Style Embossed	Minimum Bend Radius 6	Minimum Bend Radius 6	Minimum Working Temperature -40	Product Width 1.54	Qualified Hose Fittings 6S	Reinforcement Material Wire	Supplier Part Number H47116	Tube Material Nitrile	Product Weight 62.00 lbs

Product Questions & Answers (1)

Question by: Freddie A on Sep 16, 2025, 12:46 PM

Will this hose hold up in freezing temps without cracking?

Answer by: Customer Support on Sep 17, 2025, 7:41 PM

With a minimum working temperature of -40°F, this hose is designed to function reliably in cold-weather environments.
