L2 Series 4-Way Solenoid Operated Pneumatic Valve, Single Solenoid Air Pilot, Spring Return w/Flush Locking Override, 1/4 Inch NPT Ports, 110 VAC Coil, Up To 79

Description & Features

The L2 Series 4-Way Solenoid Operated Pneumatic Valve efficiently handles directional flow control for industrial applications. Designed by Numatics - c/o ASCO LP this valve features a single solenoid air pilot mechanism complemented by a spring return with flush locking override ensuring reliable performance.

This valve is engineered for versatility offering both unlubricated and lubricated service options. It supports an operating pressure range from 28" Hg Vacuum to 150 PSIG with a shift pressure between 14.5 to 150 PSIG.

Equipped with 1/4 inch NPT Ports the valve is suitable for inline or manifold mounting. Its DIN plug-in solenoid design includes an indicator light for ease of monitoring.

The unit is designed to handle temperatures ranging from -10F to +115F making it suitable for various industrial environments. Additionally the integral speed control capability provides enhanced functionality.

The flow rating stands at 79 SCFM and the CV factor is 1.7000 ensuring optimal performance in pneumatic control applications. This pneumatic valve operates at 110 VAC offering consistent and dependable electrical compatibility.

MPN: C1LC62

Specifications

Brand Asco	Actuator Type Solenoid	Body Material Aluminum	Coil Type Continuous Duty	Connection Type FNPT	Dimensions 2 in L x 1 in W x 5.38 in H	Enclosure Type IP65, NEMA 4	End Type NPT	grp Lubrication Unlubricated or Lubricated Service	Media Compressed Air, Fluid	Nominal Size 1/4 in	Number of Ports/Ways 4	Number of Positions 2	Series L2 Series	Spool Action Spring Return with Flush Locking Override	Valve Type Single Solenoid Air Pilot Valve

Similar Products

Model Number	Valve Type	Spool Action	Voltage	Ports	Flow Rating (SCFM)	CV Factor
L22BA452B000061 L2 Series Solenoid Pneumatic Valve	Single Solenoid Air Pilot	Spring Return w/Flush Locking Override	24 VDC	1/4	79	1.7000
L22BB452B000061 L2 Series Solenoid Pneumatic Valve	Double Solenoid Air Pilot	Detent w/Flush Locking Override	24 VDC	1/4	79	1.7000
L22BB452O000030 L2 Series Solenoid Pneumatic Valve	Double Solenoid Air Pilot	Detent w/Flush Locking Override	110 VAC	1/4	79	1.7000

Product Questions & Answers (1)

Question by: Dwight P on Dec 22, 2025, 8:20 PM

What kind of operating pressure range does this valve have?

Answer by: Customer Support on Dec 24, 2025, 6:06 AM

It handles operating pressures ranging from 28" Hg Vacuum all the way up to 150 PSIG.
